Power Cable NYY
- Voltage Rate: 0.6/1 KV
-
Applicable Standard: IEC 60502-1.IEC 60228, ISIRI 3569-1
-
Code Designation Of Wire According ISIRI: ( 607 ) 02
-
Construction:
CU/PVC/PVC
Conductor: Plain Annealed copper wire Or Tin Coated Wires (class 1,2,5)
Insulation Type: P.V.C / A
Filling Material: P.V.C
Sheath Material: P.V.C – ST1
-
Maximum Conductor Temperature: 70°C
- Application:
Low Voltage Power Cable For Indoor and Outdoor and Under Ground As Well As In Cable Duct.
On request, Aluminium Conductor is also available.
No. of Cores & Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|
1×1.5 RE | 0.8 | 1.4 | 5.8 | 49 |
1×2.5 RE | 0.8 | 1.4 | 6.2 | 61 |
1×4 RE | 1 | 1.4 | 7.1 | 85 |
1×6 RE | 1 | 1.4 | 7.6 | 108 |
1×10 RE | 1 | 1.4 | 8.4 | 151 |
1×16 RM | 1 | 1.4 | 9.8 | 217 |
1×25 RM | 1.2 | 1.4 | 11.1 | 316 |
1×35 RM | 1.2 | 1.4 | 12.2 | 413 |
1×50 RM | 1.4 | 1.4 | 13.7 | 545 |
1×70 RM | 1.4 | 1.4 | 15.5 | 748 |
1×95 RM | 1.6 | 1.5 | 17.6 | 1019 |
1×120 RM | 1.6 | 1.6 | 19.4 | 1264 |
1×150 RM | 1.8 | 1.6 | 21.0 | 1541 |
1×185 RM | 2 | 1.7 | 23.4 | 1919 |
1×240 RM | 2.2 | 1.8 | 26.1 | 2489 |
1×300 RM | 2.4 | 1.9 | 28.9 | 3100 |
1×400 RM | 2.6 | 2 | 32.8 | 3939 |
2×1.5 RE | 0.8 | 1.8 | 11.6 | 184 |
2×2.5 RE | 0.8 | 1.8 | 12.4 | 222 |
2×4 RE | 1 | 1.8 | 14.1 | 299 |
2×6 RE | 1 | 1.8 | 15.1 | 363 |
2×10 RE | 1 | 1.8 | 16.7 | 485 |
2×16 RM | 1 | 1.8 | 19.6 | 691 |
2×25 RM | 1.2 | 1.8 | 22.2 | 964 |
2×35 RM | 1.2 | 1.8 | 24.4 | 1230 |
2×50 RM | 1.4 | 1.8 | 27.4 | 1600 |
2×70 RM | 1.4 | 2 | 31.8 | 2216 |
2×95 RM | 1.6 | 2.1 | 35.8 | 2941 |
2×120 RM | 1.6 | 2.2 | 39.2 | 3601 |
2×150 RM | 1.8 | 2.3 | 43.0 | 4404 |
2×185 RM | 2 | 2.5 | 47.8 | 5465 |
2×240 RM | 2.2 | 2.7 | 53.2 | 6991 |
2×300 RM | 2.4 | 2.9 | 59.2 | 8715 |
3×1.5 RE | 0.8 | 1.8 | 12.0 | 206 |
3×2.5 RE | 0.8 | 1.8 | 12.9 | 254 |
3×4 RE | 1 | 1.8 | 14.8 | 350 |
3×6 RE | 1 | 1.8 | 15.9 | 434 |
3×10 RE | 1 | 1.8 | 17.6 | 592 |
3×16 RM | 1 | 1.8 | 20.7 | 850 |
3×25 RM | 1.2 | 1.8 | 23.5 | 1210 |
3×35 RM | 1.2 | 1.8 | 25.9 | 1562 |
3×50 RM | 1.4 | 1.9 | 29.3 | 2057 |
3×70 RM | 1.4 | 2 | 33.8 | 2845 |
3×95 RM | 1.6 | 2.2 | 38.3 | 3825 |
3×120 RM | 1.6 | 2.3 | 42.0 | 4703 |
3×150 RM | 1.8 | 2.4 | 46.0 | 5757 |
3×185 RM | 2 | 2.6 | 51.2 | 7157 |
3×240 RM | 2.2 | 2.8 | 57.4 | 9258 |
3×300 RM | 2.4 | 3 | 63.4 | 9258 |
4×1.5 RE | 0.8 | 1.8 | 12.8 | 240 |
4×2.5 RE | 0.8 | 1.8 | 13.8 | 300 |
4×4 RE | 1 | 1.8 | 15.9 | 419 |
4×6 RE | 1 | 1.8 | 17.1 | 524 |
4×10 RE | 1 | 1.8 | 19.1 | 730 |
4×16 RM | 1 | 1.8 | 22.5 | 1053 |
4×25 RM | 1.2 | 1.8 | 25.7 | 1519 |
4×35 RM | 1.2 | 1.9 | 28.5 | 1979 |
4×50 SM | 1.4 | 1.8 | 27.1 | 2144 |
4×70 SM | 1.4 | 1.9 | 30.7 | 2967 |
4×95 SM | 1.6 | 2.1 | 35.4 | 4074 |
4×120 SM | 1.6 | 2.2 | 38.6 | 5038 |
4×150 SM | 1.8 | 2.3 | 42.6 | 6201 |
4×185 SM | 2 | 2.5 | 47.2 | 7737 |
4×240 SM | 2.2 | 2.7 | 53.3 | 10076 |
4×300 SM | 2.4 | 2.9 | 28.7 | 12561 |
4×400 SM | 2.6 | 3.1 | 66.9 | 16018 |
5×1.5 RE | 0.8 | 1.8 | 13.6 | 277 |
5×2.5 RE | 0.8 | 1.8 | 14.7 | 349 |
5×4 RE | 1 | 1.8 | 17.1 | 495 |
5×6 RE | 1 | 1.8 | 18.5 | 628 |
No. of Cores & Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|
5×6 RE | 1 | 1.8 | 18.5 | 628 |
5×10 RE | 1 | 1.8 | 20.6 | 875 |
5×16 RM | 1 | 1.8 | 24.5 | 1277 |
5×25 RM | 1.2 | 1.9 | 28.2 | 1861 |
5×35 RM | 1.2 | 2 | 31.8 | 2470 |
5×50 RM | 1.4 | 2.1 | 36.0 | 3260 |
5×70 RM | 1.4 | 2.3 | 41.3 | 4488 |
5×95 RM | 1.6 | 2.5 | 47.2 | 6101 |
5×120 RM | 1.6 | 2.6 | 51.7 | 7503 |
5×150 RM | 1.8 | 2.8 | 56.9 | 9225 |
5×185 RM | 2 | 3 | 63.2 | 11451 |
3×25+16 RM | 1.2 —– 1 | 1.8 | 24.9 | 1400 |
3×35+16 RM | 1.2 —– 1 | 1.8 | 26.9 | 1717 |
3×50+16 SM | 1.4 —– 1.2 | 1.8 | 26.4 | 1914 |
3×70+35 SM | 1.4 —– 1.2 | 1.9 | 29.4 | 2630 |
3×95+50 SM | 1.6 —– 1.4 | 2 | 34.0 | 3604 |
3×120+70 SM | 1.6 —– 1.4 | 2.1 | 36.8 | 4525 |
3×150+70 SM | 1.8 —– 1.4 | 2.3 | 41.0 | 5679 |
3×185+95 SM | 2 —– 1.6 | 2.4 | 45.2 | 7061 |
3×240+ 120 SM | 2.2 —– 1.6 | 2.6 | 51.1 | 9120 |
3×300+150 SM | 2.4 —– 1.8 | 2.8 | 56.8 | 11380 |
3×400+185 SM | 2.6 —— 2 | 3 | 64.4 | 13790 |
Power Cable N2XY
- Voltage Rate: 0.6/1 KV
Applicable Standard: IEC 60502-1.IEC 60228, ISIRI 3569-1
Code Designation Of Wire According ISIRI: ( 607 ) 02
Construction:
Conductor: Plain Annealed Copper Wire Or Tin Coated Wires (class 1,2)
Insulation Type: XLPE
Filling Material: PVC
Sheath Material: PVC 90 -ST2
Maximum Conductor Temperature: 90°C
- Application:
For Outdoors And Indoors Installation, In Damp And Wet Locations Laid Direct In The Graound (When Properly Protected) In Ducts, In Trenches And In Steel And In Steel Support Brackets.
On request, Aluminium Conductor is also available.
No. of Cores & Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|
1×1.5 RE | 0.7 | 1.4 | 5.6 | 45 |
1×2.5 RE | 0.7 | 1.4 | 6 | 56 |
1×4 RE | 0.7 | 1.4 | 6.5 | 74 |
1×6 RE | 0.7 | 1.4 | 7 | 95 |
1×10 RE | 0.7 | 1.4 | 7.8 | 137 |
1×16 RM | 0.7 | 1.4 | 9.2 | 199 |
1×25 RM | 0.9 | 1.4 | 10.5 | 294 |
1×35 RM | 0.9 | 1.4 | 11.6 | 389 |
1×50 RM | 1 | 1.4 | 12.9 | 510 |
1×70 RM | 1.1 | 1.4 | 14.9 | 713 |
1×95 RM | 1.1 | 1.5 | 16.6 | 964 |
1×120 RM | 1.2 | 1.5 | 18.4 | 1201 |
1×150 RM | 1.4 | 1.6 | 20.2 | 1477 |
1×185 RM | 1.6 | 1.7 | 22.6 | 1843 |
1×240 RM | 1.7 | 1.8 | 25.1 | 2390 |
1×300 RM | 1.8 | 1.8 | 27.5 | 2962 |
1×400 RM | 2 | 2 | 31.6 | 3789 |
No. of Cores & Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|
2×1.5 RE | 0.7 | 1.8 | 11.2 | 161 |
2×2.5 RE | 0.7 | 1.8 | 12 | 195 |
2×4 RE | 0.7 | 1.8 | 12.9 | 241 |
2×6 RE | 0.7 | 1.8 | 13.9 | 299 |
2×10 RE | 0.7 | 1.8 | 15.5 | 409 |
2×16 RM | 0.7 | 1.8 | 18.4 | 592 |
2×25 RM | 0.9 | 1.8 | 21 | 841 |
2×35 RM | 0.9 | 1.8 | 23.2 | 1084 |
2×50 RM | 1 | 1.8 | 25.8 | 1400 |
2×70 RM | 1.1 | 1.9 | 30 | 1947 |
2×95 RM | 1.1 | 2 | 33.6 | 2588 |
2×120 RM | 1.2 | 2.2 | 37.6 | 3242 |
2×150 RM | 1.4 | 2.3 | 41 | 3942 |
2×185 RM | 1.6 | 2.4 | 46 | 4936 |
1×240 RM | 1.7 | 2.6 | 51 | 6311 |
1×300 RM | 1.8 | 2.8 | 56.6 | 7855 |
No. of Cores & Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|
3×1.5 RE | 0.7 | 1.8 | 11.6 | 180 |
3×2.5 RE | 0.7 | 1.8 | 12.5 | 224 |
3×4 RE | 0.7 | 1.8 | 13.5 | 284 |
3×6 RE | 0.7 | 1.8 | 14.6 | 361 |
3×10 RE | 0.7 | 1.8 | 16.3 | 505 |
3×16 RM | 0.7 | 1.8 | 19.4 | 739 |
3×25 RM | 0.9 | 1.8 | 22.2 | 1069 |
3×35 RM | 0.9 | 1.8 | 24.6 | 1397 |
3×50 RM | 1 | 1.8 | 27.4 | 1818 |
3×70 RM | 1.1 | 2 | 32.5 | 2586 |
3×95 RM | 1.1 | 2.1 | 36.0 | 3430 |
3×120 RM | 1.2 | 2.2 | 40.1 | 4280 |
3×150 RM | 1.4 | 2.4 | 44.3 | 5276 |
3×185 RM | 1.6 | 2.5 | 49.3 | 6558 |
3×240 RM | 1.7 | 2.7 | 55.0 | 8469 |
3×300 RM | 1.8 | 2.9 | 60.6 | 10635 |
No. of Cores & Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|
4×1.5 RE | 0.7 | 1.8 | 12.3 | 208 |
4×2.5 RE | 0.7 | 1.8 | 13.3 | 263 |
4×4 RE | 0.7 | 1.8 | 14.5 | 342 |
4×6 RE | 0.7 | 1.8 | 15.7 | 438 |
4×10 RE | 0.7 | 1.8 | 17.6 | 623 |
4×16 RM | 0.7 | 1.8 | 21.1 | 920 |
4×25 RM | 0.9 | 1.8 | 24.2 | 1344 |
4×35 RM | 0.9 | 1.8 | 26.9 | 1767 |
4×50 SM | 1 | 1.8 | 25.1 | 1952 |
4×70 SM | 1.1 | 1.9 | 29.2 | 2761 |
4×95 SM | 1.1 | 2 | 32.8 | 3747 |
4×120 SM | 1.2 | 2.1 | 36.5 | 4697 |
4×150 SM | 1.4 | 2.3 | 40.7 | 5811 |
4×185 SM | 1.6 | 2.4 | 45.0 | 7237 |
4×240 SM | 1.7 | 2.6 | 50.7 | 9431 |
4×300 SM | 1.8 | 2.7 | 55.4 | 11726 |
4×400 SM | 2 | 3 | 63.8 | 15021 |
No. of Cores & Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|
5×1.5 RE | 0.7 | 1.8 | 13.1 | 241 |
5×2.5 RE | 0.7 | 1.8 | 14.2 | 309 |
5×4 RE | 0.7 | 1.8 | 15.5 | 405 |
5×6 RE | 0.7 | 1.8 | 16.8 | 523 |
5×10 RE | 0.7 | 1.8 | 19.0 | 758 |
5×16 RM | 0.7 | 1.8 | 22.9 | 1128 |
5×25 RM | 0.9 | 1.8 | 26.4 | 1661 |
5×35 RM | 0.9 | 1.9 | 29.6 | 2207 |
5×50 RM | 1 | 2 | 33.7 | 2938 |
5×70 RM | 1.1 | 2.2 | 39.5 | 4141 |
5×95 RM | 1.1 | 2.4 | 44.3 | 5573 |
5×120 RM | 1.2 | 2.6 | 49.6 | 6986 |
5×150 RM | 1.4 | 2.7 | 54.5 | 8579 |
5×185 RM | 1.6 | 2.9 | 60.8 | 10685 |
No. of Cores & Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|
3×25+16 RM | 0.9 —– 0.7 | 1.8 | 23.5 | 1256 |
3×35+16 RM | 0.9 —– 0.7 | 1.8 | 25.4 | 1552 |
3×50+25 SM | 1 —– 0.9 | 1.8 | 24.5 | 1774 |
3×70+35 SM | 1.1 —– 0.9 | 1.9 | 27.9 | 2482 |
3×95+50 SM | 1.1 —– 1 | 2 | 31.5 | 3365 |
3×120+70 SM | 1.2 —– 1.1 | 2.1 | 34.8 | 4290 |
3×150+70 SM | 1.4 —– 1.1 | 2.2 | 39.0 | 5381 |
3×185+95 SM | 1.6 —– 1.1 | 2.4 | 43.2 | 6716 |
3×240+ 120 SM | 1.7 —– 1.2 | 2.5 | 48.6 | 8661 |
3×300+150 SM | 1.4 —– 1.8 | 2.7 | 53.8 | 10805 |
3×400+185 SM | 2 —— 1.6 | 2.9 | 61.4 | 13346 |
Concentric Power Cable NYCY
- Voltage Rate: 0.6/1 KV
Applicable Standard: IEC 60502-1.IEC 60228, ISIRI 3569-1
Construction:
Conductor: Plain Annealed Copper Wire Or Tin Coated Wires (class 1,2)
Insulation Type: P.V.C / A
Bedding Material: P.V.C
Concentric material: Copper Wire + Copper Tape
Sheath Material: P.V.C – ST1
Maximum Conductor Temperature: 70°C
- Application:
Predominantly Designed For Installation In Industrial And Control Equipment, ln Power House And Where Ever A High Level Of Both Electrical And Mechanical Protection Is Required.
On request, Aluminium Conductor is also available.
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer Thickness (mm) | Nominal concentric Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
1×1.5 RE/1.5 | 0.8 | 0 | 0.5 | 1.4 | 7.0 | 77 |
1×2.5 RE/2.5 | 0.8 | 0 | 0.5 | 1.4 | 7.4 | 98 |
1×4 RE/4 | 1 | 0 | 0.8 | 1.4 | 8.9 | 142 |
1×6 RE/6 | 1.2 | 0 | 0.8 | 1.4 | 9.8 | 191 |
1×10 RE/10 | 1 | 0 | 0.8 | 1.4 | 10.2 | 264 |
1×16 RM/16 | 1 | 0 | 0.8 | 1.4 | 11.6 | 387 |
1×25 RM/25 | 1.2 | 0 | 0.9 | 1.4 | 13.1 | 569 |
1×35 RM/35 | 1.2 | 0 | 0.9 | 1.4 | 14.2 | 759 |
1×50 RM/50 | 1.4 | 0 | 0.9 | 1.5 | 15.9 | 998 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer Thickness (mm) | Nominal concentric Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
2×1.5 RE/1.5 | 0.8 | 1 | 0.5 | 1.8 | 12.8 | 221 |
2×2.5 RE/2.5 | 0.8 | 1 | 0.5 | 1.8 | 13.6 | 269 |
2×4 RE/4 | 1 | 1 | 0.8 | 1.8 | 16.9 | 451 |
2×6 RE/6 | 1 | 1 | 0.8 | 1.8 | 16.9 | 451 |
2×10 RE/10 | 1 | 1 | 0.8 | 1.8 | 18.5 | 612 |
2×16 RM/16 | 1 | 1 | 0.8 | 1.8 | 21.4 | 876 |
2×25 RM/25 | 1.2 | 1 | 0.9 | 1.8 | 24.2 | 1234 |
2×35 RM/35 | 1.2 | 1 | 0.9 | 1.8 | 26.4 | 1595 |
2×50 RM/50 | 1.4 | 1 | 0.9 | 1.9 | 29.6 | 2081 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer Thickness (mm) | Nominal concentric Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
3×1.5 RE/1.5 | 0.8 | 1 | 0.5 | 1.8 | 13.2 | 243 |
3×2.5 RE/2.5 | 0.8 | 1 | 0.5 | 1.8 | 14.1 | 301 |
3×4 RE/4 | 1 | 1 | 0.8 | 1.8 | 16.6 | 419 |
3×6 RE/6 | 1 | 1 | 0.8 | 1.8 | 17.7 | 523 |
3×10 RE/10 | 1 | 1 | 0.8 | 1.8 | 19.4 | 720 |
3×16 RM/16 | 1 | 1 | 0.8 | 1.8 | 22.5 | 1037 |
3×25 RM/25 | 1.2 | 1 | 0.8 | 1.8 | 25.3 | 1433 |
3×35 RM/35 | 1.2 | 1 | 0.9 | 1.9 | 28.1 | 1942 |
3×50 RM/50 | 1.4 | 1 | 0.9 | 2 | 31.5 | 2484 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer Thickness (mm) | Nominal concentric Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
4×1.5 RE/1.5 | 0.8 | 1 | 0.5 | 1.8 | 14.0 | 269 |
4×2.5 RE/2.5 | 0.8 | 1 | 0.5 | 1.8 | 15.0 | 338 |
4×4 RE/4 | 1 | 1 | 0.8 | 1.8 | 17.7 | 474 |
4×6 RE/6 | 1 | 1 | 0.8 | 1.8 | 18.9 | 597 |
4×10 RE/10 | 1 | 1 | 0.8 | 1.8 | 20.9 | 838 |
4×16 RM/16 | 1 | 1 | 0.8 | 1.8 | 24.3 | 1210 |
4×25 RM/25 | 1.2 | 1 | 0.9 | 1.8 | 27.7 | 1752 |
4×35 RM/35 | 1.2 | 1 | 0.9 | 1.8 | 27.7 | 2089 |
4×50 RM/50 | 1.4 | 1 | 0.9 | 2 | 31.5 | 2771 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer Thickness (mm) | Nominal concentric Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
5×1.5 RE/1.5 | 0.8 | 1 | 0.5 | 1.8 | 14.8 | 305 |
5×2.5 RE/2.5 | 0.8 | 1 | 0.5 | 1.8 | 15.9 | 386 |
5×4 RE/4 | 1 | 1 | 0.8 | 1.8 | 18.9 | 550 |
5×6 RE/6 | 1 | 1 | 0.8 | 1.8 | 20.3 | 699 |
5×10 RE/10 | 1 | 1 | 0.8 | 1.8 | 22.4 | 981 |
5×16 RM/16 | 1 | 1 | 0.8 | 1.8 | 26.3 | 1431 |
5×25 RM/25 | 1.2 | 1 | 0.9 | 1.9 | 30.2 | 2091 |
5×35 RM/35 | 1.2 | 1.2 | 0.9 | 2 | 33.8 | 2782 |
5×50 RM/50 | 1.4 | 1.2 | 0.9 | 2.2 | 38.2 | 3676 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer Thickness (mm) | Nominal concentric Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
3×25+16 RM/16 | 1.2 —– 1 | 1 | 0.8 | 1.8 | 26.7 | 1554 |
3×35+16 RM/16 | 1.2 —– 1 | 1 | 0.8 | 1.9 | 28.9 | 1885 |
3×50+25 RM/25 | 1.4 —– 1.2 | 1 | 0.9 | 1.8 | 30.4 | 2319 |
3×70+35 RM/35 | 1.4 —– 1.2 | 1.2 | 0.9 | 1.9 | 33.7 | 3169 |
3×95+50 RM/50 | 1.6 —– 1.4 | 1.2 | 0.9 | 2 | 38.4 | 4279 |
Concentric Power Cable N2XCY
- Voltage Rate: 0.6/1 KV
Applicable Standard: IEC 60502-1,IEC 60228, ISIRI 3569-1
Construction:
Conductor: Plain Annealed Copper Wire Or Tin Coated Wires (class 1,2)
Insulation Type: XLPE
Bedding Material: P.V.C
Concentric material: Copper Wire + Copper Tape
Sheath Material: P.V.C 90 – ST2
Maximum Conductor Temperature: 70°C
- Application:
For Outdoor Installation In Damp And Wet Location, Laid Direct In, The Ground Where Excessive Mechanical Stresses Are Required In Sloping And Movable Terrains And In Vertical Or Inclined Laying, As Well As In Locations Susceptible To Sliding.
On request, Aluminium Conductor is also available.
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer Thickness (mm) | Nominal concentric Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
1×1.5 RE/1.5 | 0.7 | 0 | 0.5 | 1.4 | 6.8 | 81 |
1×2.5 RE/2.5 | 0.7 | 0 | 0.5 | 1.4 | 7.2 | 104 |
1×4 RE/4 | 0.7 | 0 | 0.8 | 1.4 | 8.3 | 148 |
1×6 RE/6 | 0.7 | 0 | 0.8 | 1.4 | 8.8 | 190 |
1×10 RE/10 | 0.7 | 0 | 0.8 | 1.4 | 9.6 | 273 |
1×16 RM/16 | 0.7 | 0 | 0.8 | 1.4 | 11 | 398 |
1×25 RM/25 | 0.9 | 0 | 0.9 | 1.4 | 12.5 | 585 |
1×35 RM/35 | 0.9 | 0 | 0.9 | 1.4 | 13.6 | 778 |
1×50 RM/50 | 1 | 0 | 0.9 | 1.4 | 14.9 | 1005 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer Thickness (mm) | Nominal concentric Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
2×1.5 RE/1.5 | 0.7 | 1 | 0.5 | 1.8 | 12.4 | 220 |
2×2.5 RE/2.5 | 0.7 | 1 | 0.5 | 1.8 | 13.2 | 266 |
2×4 RE/4 | 0.7 | 1 | 0.8 | 1.8 | 14.7 | 351 |
2×6 RE/6 | 0.7 | 1 | 0.8 | 1.8 | 15.7 | 433 |
2×10 RE/10 | 0.7 | 1 | 0.8 | 1.8 | 17.3 | 590 |
2×16 RM/16 | 0.7 | 1 | 0.8 | 1.8 | 20.2 | 846 |
2×25 RM/25 | 0.9 | 1 | 0.9 | 1.8 | 23.0 | 1201 |
2×35 RM/35 | 0.9 | 1 | 0.9 | 1.8 | 25.2 | 1554 |
2×50 RM/50 | 1 | 1 | 0.9 | 1.8 | 27.8 | 1987 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer Thickness (mm) | Nominal concentric Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
3×1.5 RE/1.5 | 0.7 | 1 | 0.5 | 1.8 | 12.8 | 241 |
3×2.5 RE/2.5 | 0.7 | 1 | 0.5 | 1.8 | 13.7 | 298 |
3×4 RE/4 | 0.7 | 1 | 0.8 | 1.8 | 15.3 | 398 |
3×6 RE/6 | 0.7 | 1 | 0.8 | 1.8 | 16.4 | 500 |
3×10 RE/10 | 0.7 | 1 | 0.8 | 1.8 | 18.1 | 693 |
3×16 RM/16 | 0.7 | 1 | 0.8 | 1.8 | 21.2 | 1000 |
3×25 RM/25 | 0.9 | 1 | 0.8 | 1.8 | 24.0 | 1383 |
3×35 RM/35 | 0.9 | 1 | 0.9 | 1.8 | 26.6 | 1880 |
3×35 RM/16 | 0.9 | 1 | 0.9 | 1.8 | 23.8 | 1592 |
3×50 RM/50 | 1 | 1 | 0.9 | 1.9 | 29.6 | 2436 |
3×50 RM/16 | 1 | 1 | 0.9 | 1.8 | 26.2 | 2067 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer Thickness (mm) | Nominal concentric Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
4×1.5 RE/1.5 | 0.7 | 1 | 0.5 | 1.8 | 13.5 | 272 |
4×2.5 RE/2.5 | 0.7 | 1 | 0.5 | 1.8 | 14.5 | 341 |
4×4 RE/4 | 0.7 | 1 | 0.8 | 1.8 | 16.3 | 462 |
4×6 RE/6 | 0.7 | 1 | 0.8 | 1.8 | 17.5 | 584 |
4×10 RE/10 | 0.7 | 1 | 0.8 | 1.8 | 19.4 | 819 |
4×16 RM/16 | 0.7 | 1 | 0.8 | 1.8 | 22.9 | 1194 |
4×25 RM/16 | 0.9 | 1 | 0.9 | 1.8 | 26.2 | 1732 |
4×35 RM/35 | 0.9 | 1 | 0.9 | 1.9 | 29.1 | 2284 |
4×50 RM/50 | 1 | 1 | 0.9 | 1.9 | 29.3 | 2584 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer Thickness (mm) | Nominal concentric Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
5×1.5 RE/1.5 | 0.7 | 1 | 0.5 | 1.8 | 14.3 | 308 |
5×2.5 RE/2.5 | 0.7 | 1 | 0.5 | 1.8 | 15.4 | 389 |
5×4 RE/4 | 0.7 | 1 | 0.8 | 1.8 | 17.3 | 528 |
5×6 RE/6 | 0.7 | 1 | 0.8 | 1.8 | 18.6 | 671 |
5×10 RE/10 | 0.7 | 1 | 0.8 | 1.8 | 20.8 | 955 |
5×16 RM/16 | 0.7 | 1 | 0.8 | 1.8 | 24.7 | 1400 |
5×25 RM/16 | 0.9 | 1 | 0.9 | 1.9 | 28.6 | 2059 |
5×35 RM/35 | 0.9 | 1.2 | 0.9 | 2.0 | 32.2 | 2746 |
5×50 RM/50 | 1 | 1.2 | 0.9 | 2.1 | 35.9 | 3572 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer Thickness (mm) | Nominal concentric Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
3×25+16 | 0.9 —–0.7 | 1 | 0.8 | 1.8 | 25.3 | 1532 |
3×35+16 | 0.9 —– 0.7 | 1 | 0.8 | 1.8 | 27.2 | 1839 |
3×50+25 | 1.1 —– 0.9 | 1 | 0.9 | 1.8 | 28.5 | 1360 |
3×70+35 | 1.1 —– 0.9 | 1.2 | 0.9 | 1.9 | 32.4 | 3023 |
3×95+50 | 1.1 —– 1 | 1.2 | 0.9 | 2 | 36.1 | 4037 |
Armoured Power Cable NYRY
- Voltage Rate: 0.6/1 KV
Applicable Standard: IEC 60502-1,IEC 60228, ISIRI 3569-1
Construction:
Conductor: Plain Annealed Copper Wire Or Tin Coated Wires (class 1.2)
Insulation Type: P.V.C / A
Bedding Material: PVC
Armour material: Galvanized Steel Wire/Aluminium Wire
Sheath Material: P.V.C – ST1
Maximum Conductor Temperature: 70°C
- Application:
For Outdoor And Indoor Installation and Wet Location Laid Direct To The Ground, Where Mechanical Damages Are Expected To Occur.
On request, Aluminium Conductor is also available.
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer Thickness (mm) | Nominal concentric Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
1×25 RM | 1.2 | 1 | 1.25 | 1.4 | 15.6 | 475 |
1×35 RM | 1.2 | 1 | 1.25 | 1.5 | 16.9 | 595 |
1×50 RM | 1.4 | 1 | 1.25 | 1.5 | 18.4 | 744 |
1×70 RM | 1.4 | 1 | 1.25 | 1.6 | 20.4 | 983 |
1×95 RM | 1.6 | 1 | 1.6 | 1.7 | 23.2 | 1329 |
1×120 RM | 1.6 | 1 | 1.6 | 1.7 | 24.8 | 1591 |
1×150 RM | 1.8 | 1 | 1.6 | 1.8 | 26.6 | 1904 |
1×185 RM | 2 | 1 | 1.6 | 1.9 | 29.0 | 2319 |
1×240 RM | 2.2 | 1 | 1.6 | 2.0 | 31.7 | 2933 |
1×300 RM | 2.4 | 1.2 | 2 | 2.1 | 35.7 | 3703 |
1×400 RM | 2.6 | 1.2 | 2 | 2.2 | 39.6 | 4612 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer Thickness (mm) | Nominal concentric Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
2×1.5 RE | 0.8 | 1 | 0.9 | 1.8 | 13.4 | 332 |
2×2.5 RE | 0.8 | 1 | 0.9 | 1.8 | 14.2 | 383 |
2×4 RE | 1 | 1 | 1.25 | 1.8 | 16.6 | 568 |
2×6 RE | 1 | 1 | 1.25 | 1.8 | 17.6 | 650 |
2×10 RE | 1 | 1 | 1.25 | 1.8 | 19.2 | 806 |
2×16 RM | 1 | 1 | 1.6 | 1.8 | 22.8 | 1181 |
2×25 RM | 1.2 | 1 | 1.6 | 1.8 | 25.4 | 1525 |
2×35 RM | 1.2 | 1 | 1.6 | 1.8 | 27.6 | 1861 |
2×50 RM | 1.4 | 1 | 1.6 | 1.9 | 30.8 | 2311 |
2×70 RM | 1.4 | 1.2 | 2 | 2.1 | 36.0 | 3254 |
2×95 RM | 1.6 | 1.2 | 2 | 2.2 | 40.0 | 4109 |
2×120 RM | 1.6 | 1.2 | 2 | 2.4 | 43.6 | 4895 |
2×150 RM | 1.8 | 1.4 | 2.5 | 2.5 | 48.4 | 6209 |
2×185 RM | 2 | 1.4 | 2.5 | 2.7 | 53.2 | 7437 |
2×240 RM | 2.2 | 1.4 | 2.5 | 2.8 | 58.4 | 9132 |
2×300 RM | 2.4 | 1.6 | 2.5 | 3.0 | 64.4 | 11074 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer Thickness (mm) | Nominal concentric Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
3×1.5 RE | 0.8 | 1 | 0.9 | 1.8 | 13.8 | 363 |
3×2.5 RE | 0.8 | 1 | 0.9 | 1.8 | 14.7 | 420 |
3×4 RE | 1 | 1 | 1.25 | 1.8 | 17.3 | 630 |
3×6 RE | 1 | 1 | 1.25 | 1.8 | 18.4 | 741 |
3×10 RE | 1 | 1 | 1.25 | 1.8 | 20.1 | 934 |
3×16 RM | 1 | 1 | 1.6 | 1.8 | 23.9 | 1391 |
3×25 RM | 0.9 | 1 | 0.8 | 1.8 | 24.0 | 1383 |
3×35 RM | 1.2 | 1 | 1.6 | 1.9 | 29.3 | 2243 |
3×50 RM | 1.4 | 1 | 2 | 2.0 | 33.5 | 3047 |
3×70 RM | 1.4 | 1.2 | 2 | 2.2 | 38.2 | 3985 |
3×95 RM | 1.6 | 1.2 | 2 | 2.3 | 42.5 | 5108 |
3×120 RM | 1.6 | 1.2 | 2.5 | 2.5 | 47.4 | 6474 |
3×150 RM | 1.8 | 1.4 | 2.5 | 2.6 | 51.4 | 7701 |
3×185 RM | 2 | 1.4 | 2.5 | 2.8 | 56.6 | 9313 |
3×240 RM | 2.2 | 1.6 | 2.5 | 3.0 | 62.8 | 11648 |
3×300 RM | 2.4 | 1.6 | 2.5 | 3.2 | 68.8 | 14097 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer Thickness (mm) | Nominal concentric Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
4×1.5 RE | 0.8 | 1 | 0.9 | 1.8 | 14.6 | 407 |
4×2.5 RE | 0.8 | 1 | 1.25 | 1.8 | 16.3 | 563 |
4×4 RE | 1 | 1 | 1.25 | 1.8 | 18.4 | 726 |
4×6 RE | 1 | 1 | 1.25 | 1.8 | 19.6 | 859 |
4×10 RE | 1 | 1 | 1.25 | 1.8 | 21.6 | 1109 |
4×16 RM | 1 | 1 | 1.6 | 1.8 | 25.7 | 1638 |
4×25 RM | 1.2 | 1 | 1.6 | 1.9 | 29.1 | 2204 |
4×35 RM | 1.2 | 1 | 1.6 | 2.0 | 31.9 | 2737 |
4×50 SM | 1.4 | 1 | 2 | 2.0 | 33.5 | 3335 |
4×70 SM | 1.4 | 1.2 | 2 | 2.2 | 37.7 | 4351 |
4×95 SM | 1.6 | 1.2 | 2 | 2.3 | 42.2 | 5649 |
4×120 SM | 1.6 | 1.2 | 2.5 | 2.5 | 46.6 | 7164 |
4×150 SM | 1.8 | 1.4 | 2.5 | 2.6 | 51.0 | 8594 |
4×185 SM | 2 | 1.4 | 2.5 | 2.7 | 55.4 | 10340 |
4×240 SM | 2.2 | 1.6 | 2.5 | 3.0 | 62.1 | 13081 |
4×300 SM | 2.4 | 1.6 | 2.5 | 3.1 | 67.3 | 15821 |
4×400 SM | 2.6 | 1.8 | 3.15 | 3.5 | 77.6 | 20715 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer Thickness (mm) | Nominal concentric Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
5×1.5 RE | 0.8 | 1 | 0.9 | 1.8 | 15.4 | 457 |
5×2.5 RE | 0.8 | 1 | 1.25 | 1.8 | 17.2 | 630 |
5×4 RE | 1 | 1 | 1.25 | 1.8 | 19.6 | 829 |
5×6 RE | 1 | 1 | 1.25 | 1.8 | 21.0 | 988 |
5×10 RE | 1 | 1 | 1.6 | 1.8 | 23.8 | 1402 |
5×16 RM | 1 | 1 | 1.6 | 1.8 | 27.7 | 1921 |
5×25 RM | 1.2 | 1 | 1.6 | 2.0 | 31.6 | 2605 |
5×35 RM | 1.2 | 1.2 | 2 | 2.1 | 36.0 | 3533 |
5×50 RM | 1.4 | 1.2 | 2 | 2.3 | 40.4 | 4476 |
5×70 RM | 1.4 | 1.2 | 2.5 | 2.5 | 46.7 | 6273 |
5×95 RM | 1.6 | 1.4 | 2.5 | 2.7 | 52.6 | 8095 |
5×120 RM | 1.6 | 1.4 | 2.5 | 2.8 | 57.1 | 9715 |
5×150 RM | 1.8 | 1.6 | 2.5 | 3.0 | 62.3 | 11601 |
5×185 RM | 2 | 1.6 | 2.5 | 3.2 | 68.6 | 14104 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer Thickness (mm) | Nominal concentric Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
3×25+16 RM | 1.2 —– 1 | 1 | 1.6 | 1.9 | 28.3 | 2055 |
3×35+16 RM | 1.2 —– 1 | 1 | 1.6 | 1.9 | 30.3 | 2458 |
3×50+25 SM | 1.4 —– 1.2 | 1 | 1.6 | 1.8 | 31.6 | 2834 |
3×70+35 SM | 1.4 —– 1.2 | 1.2 | 2 | 1.9 | 35.7 | 3927 |
3×95+50 SM | 1.6 —– 1.4 | 1.2 | 2 | 2 | 40.4 | 5083 |
3×120+70 SM | 1.6 —– 1.4 | 1.2 | 2 | 2.1 | 43.2 | 6123 |
Tape Armoured Power Cable NYBY
- Voltage Rate: 0.6/1 KV
Applicable Standard: IEC 60502-1,IEC 60228,VDE 0295, ISIRI 3569-1
Construction:
Conductor: Plain Annealed Copper Wire Or Tin Coated Wires (class 1,2)
Insulation Type: P.V.C
Bedding Material: P.V.C
Armour material: Galvanized Steel Tape / Aluminium tape
Sheath Material: P.V.C
Maximum Conductor Temperature: 70°C
- Application:
For Outdoor And Indoor Installation and Wet Location Laid Direct To The Ground, Where Mechanical Damages Are Expected To Occur.
On request, Aluminium Conductor is also available.
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Armour Tape Thickness (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|
1×35 RM | 1.2 | 0.5 | 1.5 | 18.0 | 588 |
1×50 RM | 1.4 | 0.5 | 1.6 | 19.7 | 745 |
1×70 RM | 1.4 | 0.5 | 1.6 | 21.5 | 970 |
1×95 RM | 1.6 | 0.5 | 1.7 | 23.6 | 1266 |
1×120 RM | 1.6 | 0.5 | 1.8 | 25.4 | 1532 |
1×150 RM | 1.8 | 0.5 | 1.8 | 27.0 | 1828 |
1×185 RM | 2 | 0.5 | 1.9 | 29.4 | 2235 |
1×240 RM | 2.2 | 0.5 | 2.0 | 32.1 | 2837 |
1×300 RM | 2.4 | 0.5 | 2.1 | 34.9 | 3481 |
1×400 RM | 2.6 | 0.5 | 2.2 | 39.2 | 4402 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Armour Tape Thickness (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|
2×1.5 RE | 0.8 | 0.2 | 1.8 | 13.4 | 256 |
2×2.5 RE | 0.8 | 0.2 | 1.8 | 14.2 | 297 |
2×4 RE | 1 | 0.2 | 1.8 | 15.9 | 382 |
2×6 RE | 1 | 0.2 | 1.8 | 16.9 | 451 |
2×10 RE | 1 | 0.2 | 1.8 | 18.5 | 579 |
2×16 RM | 1 | 0.2 | 1.8 | 21.4 | 794 |
2×25 RM | 1.2 | 0.2 | 1.8 | 24.0 | 1074 |
2×35 RM | 1.2 | 0.2 | 1.8 | 26.2 | 1342 |
2×50 RM | 1.4 | 0.2 | 1.9 | 29.4 | 1729 |
2×70 RM | 1.4 | 0.2 | 2 | 33.2 | 2301 |
2×95 RM | 1.6 | 0.2 | 2.2 | 37.8 | 3070 |
2×120 RM | 1.6 | 0.5 | 2.3 | 43.0 | 4149 |
2×150 RM | 1.8 | 0.5 | 2.5 | 46.6 | 4956 |
2×185 RM | 2 | 0.5 | 2.6 | 51.6 | 6080 |
2×240 RM | 2.2 | 0.5 | 2.8 | 57.0 | 7634 |
2×300 RM | 2.4 | 0.5 | 3.0 | 63.0 | 9383 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Armour Tape Thickness (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|
3×1.5 RE | 0.8 | 0.2 | 1.8 | 13.8 | 280 |
3×2.5 RE | 0.8 | 0.2 | 1.8 | 14.7 | 333 |
3×4 RE | 1 | 0.2 | 1.8 | 16.6 | 439 |
3×6 RE | 1 | 0.2 | 1.8 | 17.7 | 528 |
3×10 RE | 1 | 0.2 | 1.8 | 19.4 | 691 |
3×16 RM | 1 | 0.2 | 1.8 | 22.5 | 961 |
3×25 RM | 1.2 | 0.2 | 1.8 | 25.3 | 1328 |
3×35 RM | 1.2 | 0.2 | 1.8 | 27.7 | 1684 |
3×50 RM | 1.4 | 0.2 | 1.8 | 25.7 | 1753 |
3×70 RM | 1.4 | 0.2 | 1.9 | 28.9 | 2383 |
3×95 RM | 1.6 | 0.2 | 2 | 32.8 | 3216 |
3×120 RM | 1.6 | 0.2 | 2.1 | 35.4 | 3950 |
3×150 RM | 1.8 | 0.5 | 2.3 | 41.2 | 5258 |
3×185 RM | 2 | 0.5 | 2.4 | 45.1 | 6452 |
3×240 RM | 2.2 | 0.5 | 2.6 | 50.4 | 8280 |
3×300 RM | 2.4 | 0.5 | 2.7 | 55.0 | 10156 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Armour Tape Thickness (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|
4×1.5 RE | 0.8 | 0.2 | 1.8 | 14.6 | 319 |
4×2.5 RE | 0.8 | 0.2 | 1.8 | 15.6 | 384 |
4×4 RE | 1 | 0.2 | 1.8 | 17.7 | 513 |
4×6 RE | 1 | 0.2 | 1.8 | 19.8 | 719 |
4×6 RE | 1 | 0.2 | 1.8 | 18.9 | 656 |
4×10 RM | 1 | 0.2 | 1.8 | 22.0 | 950 |
4×10 RE | 1 | 0.2 | 1.8 | 20.9 | 837 |
4×16 RM | 1 | 0.2 | 1.8 | 24.3 | 1171 |
4×25 RM | 1.2 | 0.2 | 1.8 | 27.5 | 1645 |
4×35 RM | 1.2 | 0.2 | 1.9 | 30.3 | 2108 |
4×35 SM | 1.2 | 0.2 | 1.8 | 27.7 | 1789 |
4×50 RM | 1.4 | 0.2 | 2.1 | 34.4 | 2892 |
4×50 SM | 1 | 0.2 | 2 | 31.3 | 2477 |
4×70 RM | 1.1 | 0.5 | 2.2 | 39.7 | 4312 |
4×70 SM | 1.1 | 0.2 | 2.1 | 35.3 | 3363 |
4×95 RM | 1.1 | 0.5 | 2.4 | 43.7 | 5528 |
4×95 SM | 1.1 | 0.5 | 2.3 | 41.8 | 4928 |
4×120 RM | 1.2 | 0.5 | 2.5 | 48.7 | 6818 |
4×120 SM | 1.2 | 0.5 | 2.4 | 45.0 | 5952 |
4×150 RM | 1.4 | 0.5 | 2.7 | 52.9 | 8191 |
4×150 SM | 1.4 | 0.5 | 2.6 | 49.6 | 7264 |
4×185 RM | 1.6 | 0.5 | 2.9 | 59.1 | 10117 |
4×185 SM | 1.6 | 0.5 | 2.7 | 54.0 | 8865 |
4×240 RM | 1.7 | 0.5 | 3.1 | 65.0 | 12727 |
4×240 SM | 1.7 | 0.5 | 2.9 | 60.5 | 11376 |
4×300 RM | 1.8 | 0.5 | 3.3 | 71.2 | 15541 |
4×300 SM | 1.8 | 0.5 | 3.1 | 65.9 | 13958 |
4×400 RM | 2 | 0.5 | 3.6 | 81.2 | 19713 |
4×400 SM | 2 | 0.5 | 3.4 | 74.3 | 17604 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Armour Tape Thickness (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|
5×1.5 RE | 0.7 | 0.5 | 1.8 | 16.6 | 568 |
5×1.5 RE | 0.7 | 0.2 | 1.8 | 14.9 | 342 |
5×2.5 RM | 0.7 | 0.2 | 1.8 | 16.6 | 489 |
5×2.5 RE | 0.7 | 0.2 | 1.8 | 16.0 | 420 |
5×4 RM | 0.7 | 0.2 | 1.8 | 18.1 | 610 |
5×4 RE | 0.7 | 0.2 | 1.8 | 17.3 | 528 |
5×6 RM | 0.7 | 0.2 | 1.8 | 19.6 | 755 |
5×6 RE | 0.7 | 0.2 | 1.8 | 18.6 | 658 |
5×10 RM | 0.7 | 0.2 | 1.8 | 22.1 | 1031 |
5×10 RE | 0.7 | 0.2 | 1.8 | 20.8 | 913 |
5×16 RM | 0.7 | 0.2 | 1.8 | 24.7 | 1317 |
5×25 RM | 0.9 | 0.2 | 1.9 | 28.4 | 1903 |
5×35 RM | 0.9 | 0.2 | 2 | 31.6 | 2480 |
5×50 RM | 1 | 0.2 | 2.1 | 35.7 | 3254 |
5×70 RM | 1.1 | 0.5 | 2.4 | 43.5 | 4968 |
5×95 RM | 1.1 | 0.5 | 2.5 | 48.1 | 6477 |
5×120 RM | 1.2 | 0.5 | 2.7 | 53.4 | 8007 |
5×150 RM | 1.4 | 0.5 | 2.8 | 58.3 | 9720 |
5×185 RM | 1.6 | 0.5 | 3.1 | 64.8 | 12012 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Armour Tape Thickness (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|
3×25+16 RM | 0.9 —– 0.7 | 0.2 | 1.8 | 25.3 | 1461 |
3×35+16 RM | 0.9 —– 0.7 | 0.2 | 1.9 | 29.4 | 1950 |
3×50+25 SM | 1 —– 0.9 | 0.2 | 1.9 | 30.4 | 2247 |
3×70+35 SM | 1.1 —– 0.9 | 0.2 | 2 | 33.4 | 2953 |
3×95+50 SM | 1.1 —– 1 | 0.2 | 2.2 | 38.5 | 4085 |
3×120+70 SM | 1.2 —– 1.1 | 0.5 | 2.3 | 43.1 | 5470 |
3×150+70 SM | 1.4 —– 1.1 | 0.5 | 2.5 | 47.4 | 6710 |
3×185+95 SM | 1.6 —– 1.1 | 0.5 | 2.6 | 51.9 | 8099 |
3×240+120 SM | 1.7 —– 1.2 | 0.5 | 2.8 | 57.9 | 10442 |
3×300+150 SM | 1.8 —– 1.4 | 0.5 | 3 | 64.0 | 12906 |
3×400+185 SM | 2 —– 1.6 | 0.5 | 3.3 | 71.7 | 15762 |
Armoured Power Cable N2XRY
- Voltage Rate: 0.6/1 KV
Applicable Standard: IEC 60502-1,IEC 60228, ISIRI 3569-1
Construction:
Conductor: Plain Annealed Copper Wire Or Tin Coated Wires (class 1,2)
Insulation Type: XLPE
Bedding Material: P.V.C 90
Armour material: Galvanized Steel Wire/Aluminium Wire
Sheath Material: P.V.C 90 – ST2
Maximum Conductor Temperature: 70°C
- Application:
For Outdoor Installation In Damp And Wet Location, Laid Direct In The Ground, Where Excessive Mechanical Stresses Are Required In Sloping And Movable Terrains And In Vertical Or InclinedLaying, As Well As In Locations Susceptible To Sliding.
On request, Aluminium Conductor is also available.
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer Thickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
1×35 RM | 0.9 | 1 | 1.25 | 1.5 | 16.3 | 560 |
1×50 RM | 1 | 1 | 1.25 | 1.5 | 17.6 | 698 |
1×70 RM | 1.1 | 1 | 1.25 | 1.6 | 19.8 | 937 |
1×95 RM | 1.1 | 1 | 1.6 | 1.7 | 22.2 | 1258 |
1×120 RM | 1.2 | 1 | 1.6 | 1.7 | 24.0 | 1521 |
1×150 RM | 1.4 | 1 | 1.6 | 1.8 | 25.8 | 1825 |
1×185 RM | 1.6 | 1 | 1.6 | 1.9 | 28.2 | 2228 |
1×240 RM | 1.7 | 1 | 1.6 | 1.9 | 30.5 | 2804 |
1×300 RM | 1.8 | 1 | 2 | 2.0 | 33.9 | 3502 |
1×400 RM | 2 | 1.2 | 2 | 2.2 | 38.4 | 4446 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer Thickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
2×1.5 RE | 0.7 | 1 | 0.9 | 1.8 | 13.0 | 312 |
2×2.5 RE | 0.7 | 1 | 0.9 | 1.8 | 13.8 | 356 |
2×4 RE | 0.7 | 1 | 0.9 | 1.8 | 14.7 | 417 |
2×6 RE | 0.7 | 1 | 1.25 | 1.8 | 16.4 | 573 |
2×10 RE | 0.7 | 1 | 1.25 | 1.8 | 18.0 | 722 |
2×16 RM | 0.7 | 1 | 1.25 | 1.8 | 20.9 | 974 |
2×25 RM | 0.9 | 1 | 1.6 | 1.8 | 24.2 | 1410 |
2×35 RM | 0.9 | 1 | 1.6 | 1.8 | 26.4 | 1718 |
2×50 RM | 1 | 1 | 1.6 | 1.9 | 29.2 | 2127 |
2×70 RM | 1.1 | 1 | 2 | 2.1 | 34.4 | 3037 |
2×95 RM | 1.1 | 1.2 | 2 | 2.2 | 38.0 | 3808 |
2×120 RM | 1.2 | 1.2 | 2 | 2.3 | 41.8 | 4575 |
2×150 RM | 1.4 | 1.2 | 2.5 | 2.4 | 46.2 | 5772 |
2×185 RM | 1.6 | 1.4 | 2.5 | 2.6 | 51.4 | 7028 |
2×240 RM | 1.7 | 1.4 | 2.5 | 2.8 | 56.4 | 8647 |
2×300 RM | 1.8 | 1.6 | 2.5 | 3.0 | 62.0 | 10434 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer Thickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
3×1.5 RE | 0.7 | 1 | 0.9 | 1.8 | 13.4 | 336 |
3×2.5 RE | 0.7 | 1 | 0.9 | 1.8 | 14.3 | 395 |
3×4 RE | 0.7 | 1 | 0.9 | 1.8 | 15.3 | 471 |
3×6 RE | 0.7 | 1 | 1.25 | 1.8 | 17.1 | 655 |
3×10 RE | 0.7 | 1 | 1.25 | 1.8 | 18.8 | 838 |
3×16 RM | 0.7 | 1 | 1.6 | 1.8 | 22.6 | 1260 |
3×25 RM | 0.9 | 1 | 1.6 | 1.8 | 25.4 | 1670 |
3×35 RM | 0.9 | 1 | 1.6 | 1.8 | 27.8 | 2078 |
3×50 RM | 1 | 1 | 1.6 | 1.9 | 30.8 | 2593 |
3×70 RM | 1.1 | 1.2 | 2 | 2.1 | 36.7 | 3738 |
3×95 RM | 1.1 | 1.2 | 2 | 2.3 | 40.4 | 4729 |
3×120 RM | 1.2 | 1.2 | 2 | 2.4 | 44.5 | 5735 |
3×150 RM | 1.4 | 1.4 | 2.5 | 2.6 | 49.7 | 7288 |
3×185 RM | 1.6 | 1.4 | 2.5 | 2.7 | 54.7 | 8811 |
3×240 RM | 1.7 | 1.6 | 2.5 | 2.9 | 60.4 | 10966 |
3×300 RM | 1.8 | 1.6 | 2.5 | 3.1 | 66.0 | 13415 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer Thickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
4×1.5 RE | 0.7 | 1 | 0.9 | 1.8 | 14.1 | 374 |
4×2.5 RE | 0.7 | 1 | 0.9 | 1.8 | 15.1 | 450 |
4×4 RE | 0.7 | 1 | 1.25 | 1.8 | 17.0 | 626 |
4×6 RE | 0.7 | 1 | 1.25 | 1.8 | 18.2 | 751 |
4×10 RE | 0.7 | 1 | 1.25 | 1.8 | 20.1 | 985 |
4×16 RM | 0.7 | 1 | 1.6 | 1.8 | 24.3 | 1490 |
4×25 RM | 0.9 | 1 | 1.6 | 1.8 | 27.4 | 2009 |
4×35 RM | 0.9 | 1 | 1.6 | 1.9 | 30.3 | 2527 |
4×50 SM | 1 | 1 | 1.6 | 1.9 | 30.5 | 2846 |
4×70 SM | 1.1 | 1.2 | 2 | 2.1 | 36.0 | 4068 |
4×95 SM | 1.1 | 1.2 | 2 | 2.2 | 39.6 | 5204 |
4×120 SM | 1.2 | 1.2 | 2 | 2.4 | 43.5 | 6349 |
4×150 SM | 1.4 | 1.4 | 2.5 | 2.5 | 48.9 | 8050 |
4×185 SM | 1.6 | 1.4 | 2.5 | 2.7 | 53.4 | 9728 |
4×240 SM | 1.7 | 1.6 | 2.5 | 2.9 | 59.5 | 12249 |
4×300 SM | 1.8 | 1.6 | 2.5 | 3.0 | 64.2 | 14866 |
4×300 SM | 2 | 1.6 | 3.15 | 3.4 | 74.1 | 19437 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer Thickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
5×1.5 RE | 0.7 | 1 | 0.9 | 1.8 | 14.9 | 423 |
5×2.5 RE | 0.7 | 1 | 1.25 | 1.8 | 16.7 | 593 |
5×4 RE | 0.7 | 1 | 1.25 | 1.8 | 18.0 | 718 |
5×6 RE | 0.7 | 1 | 1.25 | 1.8 | 19.3 | 866 |
5×10 RE | 0.7 | 1 | 1.6 | 1.8 | 22.2 | 1264 |
5×16 RM | 0.7 | 1 | 1.6 | 1.8 | 26.1 | 1762 |
5×25 RM | 0.9 | 1 | 1.6 | 1.9 | 29.8 | 2405 |
5×35 RM | 0.9 | 1 | 2 | 2.0 | 33.8 | 3257 |
5×50 RM | 1 | 1.2 | 2 | 2.2 | 38.1 | 4159 |
5×70 RM | 1.1 | 1.2 | 2 | 2.4 | 43.9 | 5570 |
5×95 RM | 1.1 | 1.4 | 2.5 | 2.6 | 49.7 | 7585 |
5×120 RM | 1.2 | 1.4 | 2.5 | 2.7 | 54.8 | 9217 |
5×150 RM | 1.4 | 1.6 | 2.5 | 2.9 | 59.9 | 11076 |
5×185 RM | 1.6 | 1.6 | 2.5 | 3.1 | 66.2 | 13465 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer Thickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
3×25+16 RM | 0.9 — 0.7 | 1 | 1.6 | 1.8 | 26.7 | 1906 |
3×35+16 RM | 0.9 — 0.7 | 1 | 1.6 | 1.9 | 28.8 | 2284 |
3×50+25 SM | 1 — 0.9 | 1 | 1.6 | 1.8 | 29.7 | 2935 |
3×70+35 SM | 1 — 0.9 | 1 | 2 | 1.85 | 33.9 | 3673 |
3×95+50 SM | 1.1 — 1 | 1.2 | 2 | 1.97 | 37.9 | 4753 |
3×120+70 SM | 1.2 — 1.1 | 1.2 | 2 | 2.07 | 41.2 | 5801 |
3×150+70 SM | 1.4 — 1.1 | 1.2 | 2.5 | 2.21 | 46.4 | 7448 |
3×185+95 SM | 1.6 — 1.1 | 1.4 | 2.5 | 2.35 | 51.0 | 9046 |
3×240+120 SM | 1.7 — 1.2 | 1.4 | 2.5 | 2.52 | 56.4 | 11263 |
3×300+150 SM | 1.8 — 1.4 | 1.6 | 2.5 | 2.69 | 62.0 | 13769 |
3×400+185 SM | 2 — 1.6 | 1.6 | 2.5 | 2.94 | 69.6 | 16681 |
Tape Armoured Power Cable N2XBY
- Voltage Rate: 0.6/1 KV
Applicable Standard: IEC 60502-1,IEC 60228,VDE 0295, ISIRI 3569-1
Construction:
Conductor: Plain Annealed Copper Wire Or Tin Coated Wires (class 1,2)
Insulation Type: XLPE
Bedding Material: P.V.C 90
Armour material: Galvanized Steel Tape / Aluminium Tape
Sheath Material: P.V.C 90 – ST2
Maximum Conductor Temperature: 90°C
- Application:
For Outdoor Installation In Damp And Wet Location, Laid Direct In The Ground, Where Excessive Mechanical Stresses Are Required In Sloping And Movable Terrains And In Vertical Or Inclined Laying ,As Well As In Locations Susceptible To Sliding
On request, Aluminium Conductor is also available.
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Armour Tape Thickness (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|
1×35 RM | 0.9 | 0.5 | 1.5 | 17.4 | 566 |
1×50 RM | 1 | 0.5 | 1.5 | 18.7 | 692 |
1×70 RM | 1.1 | 0.5 | 1.6 | 20.9 | 927 |
1×95 RM | 1.1 | 0.5 | 1.7 | 22.6 | 1198 |
1×120 RM | 1.2 | 0.5 | 1.7 | 24.4 | 1457 |
1×150 RM | 1.4 | 0.5 | 1.8 | 26.2 | 1755 |
1×185 RM | 1.6 | 0.5 | 1.9 | 28.6 | 2149 |
1×240 RM | 1.7 | 0.5 | 1.9 | 30.9 | 2713 |
1×300 RM | 1.8 | 0.5 | 2 | 33.5 | 3327 |
1×400 RM | 2 | 0.5 | 2.2 | 38.0 | 4237 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Armour Tape Thickness (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|
2×1.5 RE | 0.7 | 0.2 | 1.8 | 13.0 | 239 |
2×2.5 RE | 0.7 | 0.2 | 1.8 | 13.8 | 279 |
2×4 RE | 0.7 | 0.2 | 1.8 | 14.7 | 331 |
2×6 RE | 0.7 | 0.2 | 1.8 | 15.7 | 396 |
2×10 RE | 0.7 | 0.2 | 1.8 | 17.3 | 518 |
2×16 RM | 0.7 | 0.2 | 1.8 | 20.2 | 723 |
2×25 RM | 0.9 | 0.2 | 1.8 | 22.8 | 990 |
2×35 RM | 0.9 | 0.2 | 1.8 | 25.0 | 1250 |
2×50 RM | 1 | 0.2 | 1.8 | 27.6 | 1584 |
2×70 RM | 1.1 | 0.2 | 2 | 32.0 | 2177 |
2×95 RM | 1.1 | 0.2 | 2.1 | 35.6 | 2846 |
2×120 RM | 1.2 | 0.5 | 2.3 | 41.4 | 3936 |
2×150 RM | 1.4 | 0.5 | 2.4 | 44.8 | 4698 |
2×185 RM | 1.6 | 0.5 | 2.6 | 50.0 | 5807 |
2×240 RM | 1.7 | 0.5 | 2.7 | 54.8 | 7250 |
2×300 RM | 1.8 | 0.5 | 2.9 | 60.4 | 8894 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Armour Tape Thickness (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|
3×1.5 RE | 0.7 | 0.2 | 1.8 | 13.4 | 261 |
3×2.5 RE | 0.7 | 0.2 | 1.8 | 14.3 | 312 |
3×4 RE | 0.7 | 0.2 | 1.8 | 15.3 | 379 |
3×6 RE | 0.7 | 0.2 | 1.8 | 16.4 | 464 |
3×10 RE | 0.7 | 0.2 | 1.8 | 18.1 | 621 |
3×16 RM | 0.7 | 0.2 | 1.8 | 21.2 | 877 |
3×25 RM | 0.9 | 0.2 | 1.8 | 24.0 | 1228 |
3×35 RM | 0.9 | 0.2 | 1.8 | 26.4 | 1573 |
3×50 RM | 1 | 0.2 | 1.8 | 24.0 | 1634 |
3×70 RM | 1.1 | 0.2 | 1.8 | 27.4 | 2255 |
3×95 RM | 1.1 | 0.2 | 1.9 | 30.4 | 3014 |
3×120 RM | 1.2 | 0.2 | 2 | 33.4 | 3747 |
3×150 RM | 1.4 | 0.5 | 2.2 | 39.3 | 5007 |
3×185 RM | 1.6 | 0.5 | 2.4 | 43.4 | 6179 |
3×240 RM | 1.7 | 0.5 | 2.5 | 48.0 | 7888 |
3×300 RM | 1.8 | 0.5 | 2.6 | 52.2 | 9677 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Armour Tape Thickness (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|
4×1.5 RE | 0.7 | 0.2 | 1.8 | 14.1 | 294 |
4×2.5 RE | 0.7 | 0.2 | 1.8 | 15.1 | 357 |
4×4 RE | 0.7 | 0.2 | 1.8 | 16.3 | 444 |
4×6 RE | 1 | 0.2 | 1.8 | 19.8 | 719 |
4×6 RM | 0.7 | 0.2 | 1.8 | 18.3 | 630 |
4×6 RE | 0.7 | 0.2 | 1.8 | 17.5 | 577 |
4×10 RM | 0.7 | 0.2 | 1.8 | 20.6 | 854 |
4×10 RE | 0.7 | 0.2 | 1.8 | 19.4 | 748 |
4×16 RM | 0.7 | 0.2 | 1.8 | 22.9 | 1071 |
4×25 RM | 0.9 | 0.2 | 1.8 | 26.0 | 1517 |
4×35 RM | 0.9 | 0.2 | 1.9 | 28.9 | 1974 |
4×35 SM | 0.9 | 0.2 | 1.8 | 26.3 | 1673 |
4×50 RM | 1 | 0.2 | 2 | 32.2 | 2666 |
4×50 SM | 1 | 0.2 | 1.9 | 29.1 | 2279 |
4×70 RM | 1.1 | 0.5 | 2.2 | 39.7 | 4250 |
4×70 SM | 1.1 | 0.2 | 2 | 33.6 | 3169 |
4×95 RM | 1.1 | 0.5 | 2.4 | 43.7 | 5458 |
4×95 SM | 1.1 | 0.5 | 2.2 | 39.2 | 4604 |
4×120 RM | 1.2 | 0.5 | 2.5 | 48.7 | 6731 |
4×120 SM | 1.2 | 0.5 | 2.3 | 42.9 | 5643 |
4×150 RM | 1.4 | 0.5 | 2.7 | 52.9 | 8079 |
4×150 SM | 1.4 | 0.5 | 2.5 | 47.5 | 6904 |
4×185 RM | 1.6 | 0.5 | 2.9 | 59.1 | 9972 |
4×185 SM | 1.6 | 0.5 | 2.6 | 51.8 | 8439 |
4×240 RM | 1.7 | 0.5 | 3.1 | 65.0 | 12555 |
4×240 SM | 1.7 | 0.5 | 2.8 | 57.9 | 10831 |
4×300 RM | 1.8 | 0.5 | 3.3 | 71.2 | 15337 |
4×300 SM | 1.8 | 0.5 | 3 | 62.8 | 13287 |
4×400 RM | 2 | 0.5 | 3.6 | 81.2 | 19450 |
4×400 SM | 2 | 0.5 | 3.3 | 71.2 | 16793 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Armour Tape Thickness (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|
5×1.5 RE | 0.7 | 0.5 | 1.8 | 16.6 | 558 |
5×1.5 RE | 0.7 | 0.2 | 1.8 | 14.9 | 333 |
5×2.5 RM | 0.7 | 0.2 | 1.8 | 16.6 | 477 |
5×2.5 RE | 0.7 | 0.2 | 1.8 | 16.0 | 408 |
5×4 RM | 0.7 | 0.2 | 1.8 | 18.1 | 595 |
5×4 RE | 0.7 | 0.2 | 1.8 | 17.3 | 515 |
5×6 RM | 0.7 | 0.2 | 1.8 | 19.6 | 737 |
5×6 RE | 0.7 | 0.2 | 1.8 | 18.6 | 643 |
5×10 RM | 0.7 | 0.2 | 1.8 | 22.1 | 1010 |
5×10 RE | 0.7 | 0.2 | 1.8 | 20.8 | 894 |
5×16 RM | 0.7 | 0.2 | 1.8 | 24.7 | 1292 |
5×25 RM | 0.9 | 0.2 | 1.9 | 28.4 | 1864 |
5×35 RM | 0.9 | 0.2 | 2 | 31.6 | 2434 |
5×50 RM | 1 | 0.2 | 2.1 | 35.7 | 3196 |
5×70 RM | 1.1 | 0.5 | 2.4 | 43.5 | 4890 |
5×95 RM | 1.1 | 0.5 | 2.5 | 48.1 | 6389 |
5×120 RM | 1.2 | 0.5 | 2.7 | 53.4 | 7898 |
5×150 RM | 1.4 | 0.5 | 2.8 | 58.3 | 9581 |
5×185 RM | 1.6 | 0.5 | 3.1 | 64.8 | 11831 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Armour Tape Thickness (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|
3×25+16 RM | 0.9 —– 0.7 | 0.2 | 1.8 | 25.3 | 1424 |
3×35+16 RM | 0.9 —– 0.7 | 0.2 | 1.9 | 29.4 | 1904 |
3×50+25 SM | 1 —– 0.9 | 0.2 | 1.9 | 28.5 | 2093 |
3×70+35 SM | 1.1 —– 0.9 | 0.2 | 2 | 32.0 | 2796 |
3×95+50 SM | 1.1 —– 1 | 0.2 | 2.2 | 36.0 | 3811 |
3×120+70 SM | 1.2 —– 1.1 | 0.5 | 2.3 | 41.2 | 5196 |
3×150+70 SM | 1.4 —– 1.1 | 0.5 | 2.4 | 45.4 | 6387 |
3×185+95 SM | 1.6 —– 1.1 | 0.5 | 2.6 | 50.1 | 7742 |
3×240+120 SM | 1.7 —– 1.2 | 0.5 | 2.7 | 55.3 | 9941 |
3×300+150 SM | 1.8 —– 1.4 | 0.5 | 2.9 | 61.0 | 12286 |
3×400+185 SM | 2 —– 1.6 | 0.5 | 3.2 | 68.7 | 15038 |
Concentric -Armoured Power Cable NYCYRY
- Voltage Rate: 0.6/1 KV
Applicable Standard: IEC 60502-1,IEC 60228,VDE 0295, ISIRI 3569-1
Construction:
Conductor: Plain Annealed Copper Wire Or Tin Coated Wires (class 1,2)
Insulation Type: P.V.C / A
Bedding Material: P.V.C
Concentric material: Copper Wire + Copper Tape
Separation Sheath Material: PVC 90-ST2
Armour Material: Galvanized Steel Wire/Aluminium Wire
Sheath Material: P.V.C – ST1
Maximum Conductor Temperature: 70°C
- Application:
Predominantly Designed For Installation In Industrial And Control Equipment, In Power House And Where Ever A High Level Of Both Electrical And Mechanical Protection Is Required.
On request, Aluminium Conductor is also available.
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer hickness (mm) | Nominal Concenlric Wire Diameter (mm) | Nominal Separation Sheath Thickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|---|---|
1×16 RM/16 | 1 | 0 | 0.8 | 1.2 | 1.25 | 1.5 | 16.7 | 573 |
1×25 RM/25 | 1.2 | 0 | 0.9 | 1.2 | 1.25 | 1.5 | 18.2 | 777 |
1×35 RM/35 | 1.2 | 0 | 0.9 | 1.2 | 1.25 | 1.6 | 19.5 | 993 |
1×50 RM/50 | 1.4 | 0 | 0.9 | 1.2 | 1.6 | 1.8 | 22.1 | 1306 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer hickness (mm) | Nominal Concenlric Wire Diameter (mm) | Nominal Separation Sheath Thickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|---|---|
2×1.5 RE/1.5 | 0.8 | 1 | 0.5 | 1.2 | 1.25 | 1.8 | 17.7 | 587 |
2×2.5 RE/2.5 | 0.8 | 1 | 0.5 | 1.2 | 1.25 | 1.8 | 20.8 | 820 |
2×4 RE/4 | 1 | 1 | 0.8 | 1.2 | 1.25 | 1.8 | 20.8 | 820 |
2×6 RE/6 | 1 | 1 | 0.8 | 1.2 | 1.6 | 1.8 | 22.5 | 1045 |
2×10 RE/10 | 1 | 1 | 0.8 | 1.2 | 1.6 | 1.8 | 24.1 | 1257 |
2×16 RM/16 | 1 | 1 | 0.8 | 1.2 | 1.6 | 1.8 | 27.0 | 1606 |
2×25 RM/25 | 1.2 | 1 | 0.9 | 1.2 | 1.6 | 1.9 | 30.0 | 2087 |
2×35 RM/35 | 1.2 | 1 | 0.9 | 1.2 | 2 | 2.0 | 33.2 | 2713 |
2×50 RM/50 | 1.4 | 1 | 0.9 | 1.2 | 2 | 2.1 | 36.4 | 3330 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer hickness (mm) | Nominal Concenlric Wire Diameter (mm) | Nominal Separation Sheath Thickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|---|---|
3×1.5 RE/1.5 | 0.8 | 1 | 0.5 | 1.2 | 1.25 | 1.8 | 18.1 | 620 |
3×2.5 RE/2.5 | 0.8 | 1 | 0.5 | 1.2 | 1.25 | 1.8 | 19.0 | 701 |
3×4 RE/4 | 1 | 1 | 0.8 | 1.2 | 1.6 | 1.8 | 22.2 | 999 |
3×6 RE/6 | 1 | 1 | 0.8 | 1.2 | 1.6 | 1.8 | 23.3 | 1138 |
3×10 RE/10 | 1 | 1 | 0.8 | 1.2 | 1.6 | 1.8 | 25.0 | 1403 |
3×16 RE/16 | 1 | 1 | 0.8 | 1.2 | 1.6 | 1.9 | 28.3 | 1835 |
3×25 RM/16 | 1.2 | 1 | 0.8 | 1.2 | 1.6 | 2 | 31.3 | 2331 |
3×35 RM/35 | 1.2 | 1 | 0.9 | 1.2 | 2 | 2.1 | 34.9 | 2962 |
3×50 RM/50 | 1.4 | 1 | 0.9 | 1.2 | 2 | 2.1 | 34.9 | 3450 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer hickness (mm) | Nominal Concenlric Wire Diameter (mm) | Nominal Separation Sheath Thickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|---|---|
4×1.5 RE/1.5 | 0.8 | 1 | 0.5 | 1.2 | 1.25 | 1.8 | 18.9 | 679 |
4×2.5 RE/2.5 | 0.8 | 1 | 0.5 | 1.2 | 1.25 | 1.8 | 19.9 | 782 |
4×4 RE/4 | 1 | 1 | 0.8 | 1.2 | 1.6 | 1.8 | 23.3 | 1105 |
4×6 RE/6 | 1 | 1 | 0.8 | 1.2 | 1.6 | 1.8 | 24.5 | 1282 |
4×10 RE/10 | 1 | 1 | 0.8 | 1.2 | 1.6 | 1.8 | 26.5 | 1581 |
4×16 RM/16 | 1 | 1 | 0.8 | 1.2 | 1.6 | 1.9 | 30.1 | 2094 |
4×25 RM/16 | 1.2 | 1 | 0.9 | 1.2 | 2 | 2.1 | 34.7 | 2994 |
4×35 RM/35 | 1.2 | 1 | 0.9 | 1.2 | 2 | 2.2 | 37.6 | 3668 |
4×50 RM/50 | 1.4 | 1 | 0.9 | 1.2 | 2 | 2.2 | 38.3 | 4148 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer hickness (mm) | Nominal Concenlric Wire Diameter (mm) | Nominal Separation Sheath Thickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|---|---|
5×1.5 RE/1.5 | 0.8 | 1 | 0.5 | 1.2 | 1.25 | 1.8 | 19.8 | 743 |
5×2.5 RE/2.5 | 0.8 | 1 | 0.5 | 1.2 | 1.25 | 1.8 | 20.8 | 854 |
5×4 RE/4 | 1 | 1 | 0.8 | 1.2 | 1.6 | 1.8 | 24.5 | 1234 |
5×6 RE/6 | 1 | 1 | 0.8 | 1.2 | 1.6 | 1.8 | 25.9 | 1423 |
5×10 RE/10 | 1 | 1 | 0.8 | 1.2 | 1.6 | 1.9 | 28.2 | 1791 |
5×16 RM/16 | 1 | 1 | 0.8 | 1.2 | 2 | 2.0 | 33.1 | 2599 |
5×25 RM/16 | 1.2 | 1 | 0.9 | 1.2 | 2 | 2.1 | 37.0 | 3432 |
5×35 RM/35 | 1.2 | 1.2 | 0.9 | 1.2 | 2 | 2.3 | 40.8 | 4290 |
5×50 RM/50 | 1.4 | 1.2 | 0.9 | 1.28 | 2.5 | 2.4 | 46.2 | 5724 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer hickness (mm) | Nominal Concenlric Wire Diameter (mm) | Nominal Separation Sheath Thickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|---|---|
3×25+16 RM/16 | 1.2 — 1 | 1 | 0.8 | 1.2 | 2 | 2.0 | 33.5 | 2749 |
3×35+16 RM/16 | 1.2 — 1 | 1 | 0.8 | 1.2 | 2 | 2.1 | 35.7 | 3192 |
3×50+25 SM/25 | 1.4 — 1.2 | 1 | 0.9 | 1.2 | 2 | 1.8 | 36.8 | 3627 |
3×70+35 SM/35 | 1.4 — 1.2 | 1.2 | 0.9 | 1.2 | 2 | 1.89 | 40.2 | 4628 |
3×95+50 SM/50 | 1.6 — 1.4 | 1.2 | 0.9 | 1.29 | 2.5 | 2.05 | 46.0 | 6321 |
Concentric -Armoured Power Cable N2XCYRY
- Voltage Rate: 0.6/1 KV
Applicable Standard: IEC 60502-1,IEC 60228,VDE 0295, ISIRI 3569-1
Construction:
Conductor: Plain Annealed Copper Wire Or Tin Coated Wires (class 1,2)
Insulation Type: XLPE
Bedding Material: P.V.C
Concentric material: Copper Wire + Copper Tape
Separation Sheath Material: P.V.C 90-ST2
Armour Material: Galvanized Steel Wire/Aluminium Wire
Sheath Material: P.V.C 90 – ST2
Maximum Conductor Temperature: 70°C
- Application:
For Outdoor Installation In Damp And Wet Location, Laid Direct In The Ground, Where Excessive Mechanical Stresses Are Required In Sloping And Movable Terrains And In Vertical Or Inclined Laying, As Well As In Locations Susceptible To Sliding.
On request, Aluminium Conductor is also available.
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer hickness (mm) | Nominal Concenlric Wire Diameter (mm) | Nominal Separation Sheath Thickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|---|---|
1×16 RM/16 | 0.7 | 0 | 0.8 | 1.2 | 1.25 | 1.5 | 16.1 | 552 |
1×25 RM/26 | 0.9 | 0 | 0.9 | 1.2 | 1.25 | 1.5 | 17.6 | 751 |
1×35 RM/35 | 0.9 | 0 | 0.9 | 1.2 | 1.25 | 1.5 | 18.7 | 957 |
1×50 RM/50 | 1 | 0 | 0.9 | 1.2 | 1.6 | 1.6 | 20.9 | 1251 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer hickness (mm) | Nominal Concenlric Wire Diameter (mm) | Nominal Separation Sheath Thickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|---|---|
2×1.5 RE/1.5 | 0.7 | 1 | 0.5 | 1.2 | 1.25 | 1.8 | 17.3 | 564 |
2×2.5 RE/2.5 | 0.7 | 1 | 0.5 | 1.2 | 1.25 | 1.8 | 18.1 | 633 |
2×4 RE/4 | 0.7 | 1 | 0.8 | 1.2 | 1.25 | 1.8 | 19.6 | 746 |
2×6 RE/6 | 0.7 | 1 | 0.8 | 1.2 | 1.6 | 1.8 | 21.3 | 966 |
2×10 RE/10 | 0.7 | 1 | 0.8 | 1.2 | 1.6 | 1.8 | 22.9 | 1173 |
2×16 RM/16 | 0.7 | 1 | 0.8 | 1.2 | 1.6 | 1.8 | 25.8 | 1515 |
2×25 RM/25 | 0.9 | 1 | 0.9 | 1.2 | 1.6 | 1.9 | 28.8 | 1963 |
2×35 RM/35 | 0.9 | 1 | 0.9 | 1.2 | 2 | 2.0 | 32.0 | 2591 |
2×50 RM/50 | 1 | 1 | 0.9 | 1.2 | 2 | 2.1 | 34.8 | 3147 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer hickness (mm) | Nominal Concenlric Wire Diameter (mm) | Nominal Separation Sheath Thickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|---|---|
3×1.5 RE/1.5 | 0.7 | 1 | 0.5 | 1.2 | 1.25 | 1.8 | 17.7 | 598 |
3×2.5 RE/2.5 | 0.7 | 1 | 0.5 | 1.2 | 1.25 | 1.8 | 18.6 | 678 |
3×4 RE/4 | 0.7 | 1 | 0.8 | 1.2 | 1.6 | 1.8 | 20.9 | 917 |
3×6 RE/6 | 0.7 | 1 | 0.8 | 1.2 | 1.6 | 1.8 | 22.0 | 1053 |
3×10 RE/10 | 0.7 | 1 | 0.8 | 1.2 | 1.6 | 1.8 | 23.7 | 1297 |
3×16 RE/16 | 0.7 | 1 | 0.8 | 1.2 | 1.6 | 1.8 | 26.8 | 1707 |
3×25 RM/16 | 0.9 | 1 | 0.8 | 1.2 | 1.6 | 1.9 | 29.8 | 2193 |
3×35 RM/35 | 0.9 | 1 | 0.9 | 1.2 | 2 | 2.0 | 33.4 | 3002 |
3×50 RM/50 | 1 | 1 | 0.9 | 1.2 | 2 | 2.0 | 33.0 | 3234 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer hickness (mm) | Nominal Concenlric Wire Diameter (mm) | Nominal Separation Sheath Thickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|---|---|
4×1.5 RE/1.5 | 0.7 | 1 | 0.5 | 1.2 | 1.25 | 1.8 | 18.4 | 651 |
4×2.5 RE/2.5 | 0.7 | 1 | 0.5 | 1.2 | 1.25 | 1.8 | 19.4 | 744 |
4×4 RE/4 | 0.7 | 1 | 0.8 | 1.2 | 1.6 | 1.8 | 21.9 | 1017 |
4×6 RE/6 | 0.7 | 1 | 0.8 | 1.2 | 1.6 | 1.8 | 23.1 | 1174 |
4×10 RE/10 | 0.7 | 1 | 0.8 | 1.2 | 1.6 | 1.8 | 25.0 | 1476 |
4×16 RM/16 | 0.7 | 1 | 0.8 | 1.2 | 1.6 | 1.9 | 28.7 | 1969 |
4×25 RM/16 | 0.9 | 1 | 0.9 | 1.2 | 2 | 2.0 | 33.0 | 2832 |
4×35 RM/35 | 0.9 | 1 | 0.9 | 1.2 | 2 | 2.1 | 35.9 | 3496 |
4×50 RM/35 | 1 | 1 | 0.9 | 1.2 | 2 | 2.1 | 36.1 | 3871 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer hickness (mm) | Nominal Concenlric Wire Diameter (mm) | Nominal Separation Sheath Thickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|---|---|
5×1.5 RE/1.5 | 0.7 | 1 | 0.5 | 1.2 | 1.25 | 1.8 | 19.2 | 710 |
5×2.5 RE/2.5 | 0.7 | 1 | 0.5 | 1.2 | 1.25 | 1.8 | 20.3 | 825 |
5×4 RE/4 | 0.7 | 1 | 0.8 | 1.2 | 1.6 | 1.8 | 22.9 | 1118 |
5×6 RE/6 | 0.7 | 1 | 0.8 | 1.2 | 1.6 | 1.8 | 24.2 | 1296 |
5×10 RE/10 | 0.7 | 1 | 0.8 | 1.2 | 1.6 | 1.8 | 26.4 | 1649 |
5×16 RM/16 | 0.7 | 1 | 0.8 | 1.2 | 2 | 2.0 | 31.5 | 2453 |
5×25 RM/16 | 0.9 | 1 | 0.9 | 1.2 | 2 | 2.1 | 35.4 | 3248 |
5×35 RM/35 | 0.9 | 1.2 | 0.9 | 1.2 | 2 | 2.2 | 39.0 | 4074 |
5×50 RM/50 | 1 | 1.2 | 0.9 | 1.23 | 2.5 | 2.4 | 43.9 | 5408 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer hickness (mm) | Nominal Concenlric Wire Diameter (mm) | Nominal Separation Sheath Thickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|---|---|
3×25+16 RM/16 | 0.9 — 0.7 | 1 | 0.8 | 1.2 | 2 | 2.0 | 32.1 | 2613 |
3×35+16 RM/16 | 0.9 — 0.7 | 1 | 0.8 | 1.2 | 2 | 2.1 | 34.2 | 3019 |
3×50+25 SM/25 | 1 — 0.9 | 1 | 0.9 | 1.2 | 2 | 1.8 | 34.9 | 3421 |
3×70+35 SM/35 | 1.1 — 0.9 | 1.2 | 0.9 | 1.2 | 2 | 1.9 | 38.8 | 4417 |
3×95+50 SM/50 | 1.1 — 1 | 1.2 | 0.9 | 1.24 | 2.5 | 2 | 43.6 | 5942 |
Armoured Lead Sheathed Power Cable NYKYRY
- Voltage Rate: 0.6/1 KV
Applicable Standard: IEC 60502-1,IEC 60228,VDE 0295, ISIRI 3569-1
Construction:
Conductor: Plain Annealed Copper Wire Or Tin Coated Wires (class 1,2)
InsulationType: P.V.C/A
Bedding Material: P.V.C
Metal Sheath: Lead
Bedding Material: P.V.C
Armour material: Galvanized Steel Wire
Sheath Material: PVC – ST1
Maximum Conductor Temperature: 70°C
- Application:
For Outdoor & Indoor Installation in Oil ,Gas and Petrochemical industries & Wet Location Laid Direct To The Ground, Where Mechanical Damages Are Expected To Occur.
On request, Aluminium Conductor is also available.
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer hickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
1×25 RM | 1.2 | 1.2 | 1.6 | 1.8 | 22.7 | 1259 |
1×35 RM | 1.2 | 1.2 | 1.6 | 1.8 | 23.8 | 1430 |
1×50 RM | 1.4 | 1.2 | 1.6 | 1.8 | 25.3 | 1664 |
1×70 RM | 1.4 | 1.2 | 1.6 | 1.8 | 27.1 | 1987 |
1×95 RM | 1.6 | 1.2 | 1.6 | 1.9 | 29.2 | 2390 |
1×120 RM | 1.6 | 1.2 | 1.6 | 1.9 | 30.8 | 2734 |
1×150 RM | 1.8 | 1.3 | 2 | 2.1 | 34.6 | 3384 |
1×185 RM | 2 | 1.4 | 2 | 2.1 | 37 | 4018 |
1×240 RM | 2.2 | 1.4 | 2 | 2.2 | 39.7 | 4796 |
1×300 RM | 2.4 | 1.5 | 2 | 2.3 | 43.1 | 5788 |
1×400 RM | 2.6 | 1.6 | 2.5 | 2.6 | 49.6 | 7393 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer hickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
2×1.5 RE | 0.8 | 1.2 | 1.25 | 1.8 | 19 | 1037 |
2×2.5 RE | 0.8 | 1.2 | 1.25 | 1.8 | 19.8 | 1135 |
2×4 RE | 1 | 1.2 | 1.6 | 1.8 | 22.9 | 1514 |
2×6 RE | 1 | 1.2 | 1.6 | 1.8 | 23.9 | 1666 |
2×10 RE | 1 | 1.2 | 1.6 | 1.8 | 25.5 | 1925 |
2×16 RM | 1 | 1.2 | 1.6 | 1.9 | 28.6 | 2392 |
2×25 RM | 1.2 | 1.3 | 1.6 | 2 | 31.6 | 2987 |
2×35 RM | 1.2 | 1.3 | 2 | 2.1 | 35.6 | 3814 |
2×50 RM | 1.4 | 1.4 | 2 | 2.2 | 39 | 4626 |
2×70 RM | 1.4 | 1.5 | 2 | 2.4 | 43.6 | 5820 |
2×95 RM | 1.6 | 1.6 | 2.5 | 2.6 | 50 | 7701 |
2×120 RM | 1.6 | 1.7 | 2.5 | 2.7 | 53.6 | 8967 |
2×150 RM | 1.8 | 1.9 | 2.5 | 2.8 | 57.8 | 10606 |
2×185 RM | 2 | 2 | 2.5 | 3 | 62.8 | 12549 |
2×240 RM | 2.2 | 2.1 | 2.5 | 3.2 | 68.4 | 15075 |
2×300 RM | 2.4 | 2.3 | 3.15 | 3.5 | 77.6 | 19359 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer hickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
3×1.5 RE | 0.8 | 1.2 | 1.25 | 1.8 | 19.5 | 1098 |
3×2.5 RE | 0.8 | 1.2 | 1.25 | 1.8 | 20.3 | 1205 |
3×4 RE | 1 | 1.2 | 1.6 | 1.8 | 23.6 | 1624 |
3×6 RE | 1 | 1.2 | 1.6 | 1.8 | 25.2 | 1863 |
3×10 RE | 1 | 1.2 | 1.6 | 1.8 | 26.9 | 2188 |
3×16 RM | 1 | 1.2 | 1.6 | 1.9 | 29.7 | 2671 |
3×25 RM | 1.2 | 1.3 | 2 | 2.1 | 34.7 | 3736 |
3×35 RM | 1.2 | 1.4 | 2 | 2.2 | 37.5 | 4455 |
3×50 RM | 1.4 | 1.5 | 2 | 2.3 | 41.1 | 5986 |
3×70 RM | 1.4 | 1.6 | 2.5 | 2.5 | 48 | 8157 |
3×95 RM | 1.6 | 1.7 | 2.5 | 2.7 | 52.7 | 9829 |
3×120 RM | 1.6 | 1.8 | 2.5 | 2.8 | 56.6 | 11530 |
3×150 RM | 1.8 | 1.9 | 2.5 | 2.9 | 60.8 | 13546 |
3×185 RM | 2 | 2.1 | 2.5 | 3.1 | 66.4 | 16716 |
3×240 RM | 2.2 | 2.3 | 3.15 | 3.4 | 75.8 | 21492 |
3×300 RM | 2.4 | 2.4 | 3.15 | 3.6 | 82 | 25756 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer hickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
3×25+16 RM | 1.2 — 1 | 1.3 | 2 | 2.1 | 36.1 | 3935 |
3×35+16 RM | 1.2 — 1 | 1.4 | 2 | 2.2 | 38.5 | 4568 |
3×50+25 SM | 1.4 — 1.2 | 1.4 | 2 | 2.2 | 40 | 5072 |
3×70+35 SM | 1.4 — 1.2 | 1.5 | 2 | 2.4 | 43.8 | 6307 |
3×95+50 SM | 1.6 — 1.4 | 1.7 | 2.5 | 2.6 | 50.9 | 8598 |
3×120+70 SM | 1.6 — 1.4 | 1.7 | 2.5 | 2.7 | 53.7 | 9898 |
3×150+70 SM | 1.8 — 1.4 | 1.9 | 2.5 | 2.9 | 58.8 | 11724 |
3×185+95 SM | 2 — 1.6 | 2 | 2.5 | 3 | 63.1 | 13860 |
3×240+120 SM | 2.2 — 1.6 | 2.2 | 2.5 | 3.2 | 69.9 | 17167 |
3×300+150 SM | 2.4 — 1.8 | 2.3 | 3.15 | 3.5 | 78.6 | 21622 |
3×400+185 SM | 2.6 — 2 | 2.5 | 3.15 | 3.8 | 86.7 | 26341 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer hickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
4×1.5 RE | 0.8 | 1.2 | 1.25 | 1.8 | 20.3 | 1193 |
4×2.5 RE | 0.8 | 1.2 | 1.6 | 1.8 | 22.6 | 1506 |
4×4 RE | 1 | 1.2 | 1.6 | 1.8 | 24.7 | 1785 |
4×6 RE | 1 | 1.2 | 1.6 | 1.8 | 25.9 | 2009 |
4×10 RE | 1 | 1.2 | 1.6 | 1.9 | 28.1 | 2398 |
4×16 RM | 1 | 1.3 | 1.6 | 2 | 31.9 | 3151 |
4×25 RM | 1.2 | 1.4 | 2 | 2.2 | 37.3 | 4394 |
4×35 RM | 1.2 | 1.4 | 2 | 2.2 | 39.9 | 5160 |
4×50 SM | 1.4 | 1.5 | 2 | 2.3 | 41.1 | 5493 |
4×70 SM | 1.4 | 1.6 | 2.5 | 2.5 | 47.5 | 7472 |
4×95 SM | 1.6 | 1.7 | 2.5 | 2.6 | 52.2 | 9248 |
4×120 SM | 1.6 | 1.8 | 2.5 | 2.8 | 55.8 | 10796 |
4×150 SM | 1.8 | 1.9 | 2.5 | 2.9 | 60.4 | 12726 |
4×185 SM | 2 | 2.1 | 2.5 | 3.1 | 65.4 | 15214 |
4×240 SM | 2.2 | 2.2 | 3.15 | 3.4 | 74.9 | 19859 |
4×300 SM | 2.4 | 2.4 | 3.15 | 3.6 | 80.7 | 23649 |
4×400 SM | 2.6 | 2.6 | 3.15 | 3.9 | 89.9 | 29164 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer hickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
5×1.5 RE | 0.8 | 1.2 | 1.6 | 1.8 | 22.4 | 1453 |
5×2.5 RE | 0.8 | 1.2 | 1.6 | 1.8 | 23.5 | 1619 |
5×4 RE | 1 | 1.2 | 1.6 | 1.8 | 25.9 | 1974 |
5×6 RE | 1 | 1.2 | 1.6 | 1.8 | 27.3 | 2222 |
5×10 RE | 1 | 1.2 | 1.6 | 1.9 | 29.6 | 2680 |
5×16 RM | 1 | 1.3 | 2 | 2.1 | 35.7 | 3909 |
5×25 RM | 1.2 | 1.4 | 2 | 2.2 | 39.6 | 4975 |
5×35 RM | 1.2 | 1.5 | 2 | 2.4 | 43.6 | 6153 |
5×50 RM | 1.4 | 1.7 | 2.5 | 2.6 | 50.4 | 8309 |
5×70 RM | 1.4 | 1.8 | 2.5 | 2.8 | 55.9 | 10474 |
5×95 RM | 1.6 | 2 | 2.5 | 3 | 62.2 | 13308 |
5×120 RM | 1.6 | 2.1 | 2.5 | 3.1 | 66.9 | 15676 |
5×150 RM | 1.8 | 2.2 | 3.15 | 3.4 | 75.1 | 19624 |
5×185 RM | 2 | 2.4 | 3.15 | 3.6 | 81.8 | 23487 |
Armoured Lead Sheathed Power Cable N2XKYRY
- Voltage Rate: 0.6/1 KV
Applicable Standard: IEC 60502-1,IEC 60228,VDE 0295, ISIRI 3569-1
Construction:
Conductor: Plain Annealed Copper Wire Or Tin Coated Wires (class 1,2)
Insulation Type: XLPE
Bedding Material: P.V.C
Metal Sheath: Lead
Bedding Material: P.V.C
Armour material: Galvanized Steel Wire
Sheath Material: P.V.C – ST2
Maximum Conductor Temperature: 90°C
- Application:
For Outdoor & Indoor Installation in Oil ,Gas and Petrochemical industries & Wet Location Laid Direct To The Ground, Where Mechanical Damages Are Expected To Occur.
On request, Aluminium Conductor is also available.
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer hickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
1×25 RM | 0.9 | 1.2 | 1.25 | 1.8 | 20.8 | 1115 |
1×35 RM | 0.9 | 1.2 | 1.6 | 1.8 | 23.2 | 1364 |
1×50 RM | 1 | 1.2 | 1.6 | 1.8 | 24.5 | 1570 |
1×70 RM | 1.1 | 1.2 | 1.6 | 1.8 | 26.5 | 1910 |
1×95 RM | 1.1 | 1.2 | 1.6 | 1.9 | 28.2 | 2269 |
1×120 RM | 1.2 | 1.2 | 1.6 | 1.9 | 30 | 2625 |
1×150 RM | 1.4 | 1.3 | 1.6 | 2 | 32 | 3095 |
1×185 RM | 1.6 | 1.3 | 2 | 2.1 | 36 | 3777 |
1×240 RM | 1.7 | 1.4 | 2 | 2.2 | 38.7 | 4607 |
1×300 RM | 1.8 | 1.5 | 2 | 2.3 | 41.9 | 5561 |
1×400 RM | 2 | 1.6 | 2.5 | 2.5 | 48.2 | 7103 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer hickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
2×1.5 RE | 0.7 | 1.2 | 1.25 | 1.8 | 18.6 | 993 |
2×2.5 RE | 0.7 | 1.2 | 1.25 | 1.8 | 19.4 | 1089 |
2×4 RE | 0.7 | 1.2 | 1.25 | 1.8 | 20.4 | 1212 |
2×6 RE | 0.7 | 1.2 | 1.6 | 1.8 | 22.7 | 1526 |
2×10 RE | 0.7 | 1.2 | 1.6 | 1.8 | 24.3 | 1779 |
2×16 RM | 0.7 | 1.2 | 1.6 | 1.8 | 27.2 | 2222 |
2×25 RM | 0.9 | 1.2 | 1.6 | 1.9 | 30 | 2723 |
2×35 RM | 0.9 | 1.3 | 2 | 2.1 | 34.4 | 3609 |
2×50 RM | 1 | 1.4 | 2 | 2.2 | 37.4 | 4329 |
2×70 RM | 1.1 | 1.5 | 2 | 2.3 | 42.2 | 5552 |
2×95 RM | 1.1 | 1.6 | 2.5 | 2.5 | 47.8 | 7257 |
2×120 RM | 1.2 | 1.7 | 2.5 | 2.6 | 51.8 | 8594 |
2×150 RM | 1.4 | 1.8 | 2.5 | 2.8 | 56 | 10029 |
2×185 RM | 1.6 | 1.9 | 2.5 | 2.9 | 60.8 | 11846 |
2×240 RM | 1.7 | 2.1 | 2.5 | 3.1 | 66.2 | 14411 |
2×300 RM | 2.4 | 2.3 | 3.15 | 3.5 | 77.6 | 19359 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer hickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
3×1.5 RE | 0.7 | 1.2 | 1.25 | 1.8 | 19.1 | 1052 |
3×2.5 RE | 0.7 | 1.2 | 1.25 | 1.8 | 19.9 | 1157 |
3×4 RE | 0.7 | 1.2 | 1.25 | 1.8 | 21 | 1311 |
3×6 RE | 0.7 | 1.2 | 1.6 | 1.8 | 23.9 | 1708 |
3×10 RE | 0.7 | 1.2 | 1.6 | 1.8 | 25.6 | 2009 |
3×16 RM | 0.7 | 1.2 | 1.6 | 1.9 | 28.4 | 2495 |
3×25 RM | 0.9 | 1.3 | 1.6 | 2 | 31.6 | 3182 |
3×35 RM | 0.9 | 1.3 | 2 | 2.1 | 35.8 | 4114 |
3×50 RM | 1 | 1.4 | 2 | 2.2 | 39 | 5558 |
3×70 RM | 1.1 | 1.6 | 2.5 | 2.5 | 46.7 | 7875 |
3×95 RM | 1.1 | 1.7 | 2.5 | 2.6 | 50.4 | 9331 |
3×120 RM | 1.2 | 1.8 | 2.5 | 2.7 | 54.7 | 11059 |
3×150 RM | 1.4 | 1.9 | 2.5 | 2.9 | 59.1 | 13059 |
3×185 RM | 1.6 | 2 | 2.5 | 3 | 64.3 | 15923 |
3×240 RM | 1.7 | 2.2 | 2.5 | 3.2 | 70.4 | 19362 |
3×300 RM | 1.8 | 2.3 | 3.15 | 3.5 | 79 | 24504 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer hickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
3×25+16 RM | 0.9 — 0.7 | 1.3 | 2 | 2.1 | 34.6 | 3657 |
3×35+16 RM | 0.9 — 0.7 | 1.4 | 2 | 2.1 | 36.8 | 4280 |
3×50+25 SM | 1 — 0.9 | 1.4 | 2 | 2.2 | 38.1 | 4720 |
3×70+35 SM | 1.1 — 0.9 | 1.5 | 2 | 2.3 | 42.2 | 5974 |
3×95+50 SM | 1.1 — 1 | 1.6 | 2.5 | 2.5 | 48.2 | 7942 |
3×120+70 SM | 1.2 — 1.1 | 1.7 | 2.5 | 2.6 | 51.6 | 9358 |
3×150+70 SM | 1.4 — 1.1 | 1.8 | 2.5 | 2.8 | 56.6 | 11022 |
3×185+95 SM | 1.6 — 1.1 | 1.9 | 2.5 | 2.9 | 60.9 | 13068 |
3×240+120 SM | 1.7 — 1.2 | 2.1 | 2.5 | 3.1 | 67.1 | 16142 |
3×300+150 SM | 1.8 — 1.4 | 2.2 | 3.15 | 3.4 | 75.4 | 20328 |
3×400+185 SM | 2 — 1.6 | 2.5 | 3.15 | 3.7 | 83.7 | 25117 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer hickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
4×1.5 RE | 0.7 | 1.2 | 1.25 | 1.8 | 19.8 | 1136 |
4×2.5 RE | 0.7 | 1.2 | 1.3 | 1.8 | 20.9 | 1287 |
4×4 RE | 0.7 | 1.2 | 1.6 | 1.8 | 23.3 | 1622 |
4×6 RE | 0.7 | 1.2 | 1.6 | 1.8 | 24.5 | 1824 |
4×10 RE | 0.7 | 1.2 | 1.6 | 1.8 | 26.4 | 2197 |
4×16 RM | 0.7 | 1.2 | 1.6 | 1.9 | 26.4 | 2197 |
4×25 RM | 0.9 | 1.3 | 2 | 2.1 | 35.4 | 4027 |
4×35 RM | 0.9 | 1.4 | 2 | 2.2 | 38.5 | 4895 |
4×50 SM | 1 | 1.5 | 2 | 2.3 | 42.4 | 6023 |
4×50 SM | 1 | 1.4 | 2 | 2.2 | 38.7 | 4992 |
4×70 SM | 1.1 | 1.5 | 2 | 2.4 | 43.6 | 6443 |
4×95 SM | 1.1 | 1.6 | 2.5 | 2.6 | 49.6 | 8541 |
4×120 SM | 1.2 | 1.7 | 2.5 | 2.7 | 53.5 | 10083 |
4×150 SM | 1.4 | 1.9 | 2.5 | 2.8 | 58.3 | 12131 |
4×185 SM | 1.6 | 2 | 2.5 | 3 | 63 | 14359 |
4×240 SM | 1.7 | 2.2 | 2.5 | 3.2 | 69.5 | 17849 |
4×300 SM | 1.8 | 2.3 | 3.15 | 3.5 | 77.4 | 22261 |
4×400 SM | 2 | 2.5 | 3.15 | 3.8 | 86.6 | 27639 |
No. of Cores&Cross Section (mm2) | Nominal Insulation Thickness (mm) | Nominal Inner Layer hickness (mm) | Armour Wire Diameter (mm) | Nominal Sheath Thickness (mm) | Overall diameter (Approx) mm | Total Weight (Approx.) kg/km |
---|---|---|---|---|---|---|
5×1.5 RE | 0.7 | 1.2 | 1.25 | 1.8 | 20.6 | 1230 |
5×2.5 RE | 0.7 | 1.2 | 1.6 | 1.8 | 23 | 1549 |
5×4 RE | 0.7 | 1.2 | 1.6 | 1.8 | 24.3 | 1771 |
5×6 RE | 0.7 | 1.2 | 1.6 | 1.8 | 25.6 | 2002 |
5×10 RE | 0.7 | 1.2 | 1.6 | 1.8 | 27.8 | 2443 |
5×16 RM | 0.7 | 1.3 | 2 | 2 | 33.9 | 3636 |
5×25 RM | 0.9 | 1.4 | 2 | 2.2 | 38 | 4683 |
5×35 RM | 0.9 | 1.5 | 2 | 2.3 | 41.8 | 5789 |
5×50 RM | 1 | 1.6 | 2.5 | 2.5 | 47.9 | 7656 |
5×70 RM | 1.1 | 1.8 | 2.5 | 2.7 | 54.1 | 10011 |
5×95 RM | 1.1 | 1.9 | 2.5 | 2.9 | 59.1 | 12351 |
5×120 RM | 1.2 | 2 | 2.5 | 3 | 64.4 | 14798 |
5×150 RM | 1.4 | 2.2 | 2.5 | 3.2 | 69.9 | 17654 |
5×185 RM | 1.6 | 2.4 | 3.15 | 3.5 | 79.4 | 22584 |
آدرس دفتر تهران: خیابان شهید بهشتی، نبش میرعماد، ساختمان زمرد، طبقه دوم
تلفن:02188752014
فکس:02188757639
