کابل های کنترل و ابزار دقیق

Page content:

Flexible Unscreened Cable NYSLYO

  • Voltage Rate:  300-500 V
  • Applicable  Standard: IEC 60227, IEC 60228

  • Code Designation Of Wire According IEC: 60227 IEC 75
  • Construction:

Conductor: Plain Annealed Copper Wire or Tin Coated Wires(Class 5)

Insulation Type: P.V.C/D

Outer Sheath Type: P.V.C/ST9

  • Maximum  Conductor  Temperature: 70°C

  • Application:

    Suitable for internal/external wiring of electrical  equipment at medium mechanical stress, in dry and damp interiors as well as in industrial environments. Theses cables can be used in  machine tool  manufacturing,  machines, devices, office  machine, data processing and as a control cable for static and flexible but not for continusly flexible application where electrical protection is not required.

NYSLYO
No. of Cores & Cross Section (mm2)
Nominal insulation Thickness (mm)
Nominal Sheath Thickness (mm)
Overall Dia. (Approx.)(mm)
Total Weight Approx. (kg/km)
2×0.5
0.6
0.7
5.8
35
2×0.75
0.6
0.8
6.4
44
2×1
0.6
0.8
6.7
51
2×1.5
0.7
0.9
7.7
70
2×2.5
0.8
1.0
9.2
104
5×0.5
0.6
0.9
7.7
73
5×0.75
0.6
0.9
8.2
88
5×1
0.6
1.0
8.9
109
5×1.5
0.7
1.0
10.0
146
5×2.5
0.8
1.2
12.0
223
7×0.5
0.6
1.0
9.2
99
7×0.75
0.6
1.0
9.9
122
7×1
0.6
1.1
10.7
149
7×1.5
0.7
1.2
12.3
207
7×2.5
0.8
1.4
14.7
314
No. of Cores & Cross Section (mm2)
Nominal insulation Thickness (mm)
Nominal Sheath Thickness (mm)
Overall Dia. (Approx.)(mm)
Total Weight Approx. (kg/km)
12×0.5
0.6
1.1
11.2
157
12×0.75
0.6
1.2
12.2
199
12×1
0.6
1.2
13.0
238
12×1.5
0.7
1.4
15.0
335
12×2.5
0.8
1.6
18.0
513
19×0.5
0.6
1.3
13.3
236
19×0.75
0.6
1.3
14.4
298
19×1
0.6
1.4
15.5
363
19×1.5
0.7
1.6
17.9
513
19×2.5
0.8
1.8
21.3
779
24×0.5
0.6
1.4
15.7
302
24×0.75
0.6
1.5
17.1
384
24×1
0.6
1.6
18.4
467
24×1.5
0.7
1.8
21.2
657
24×2.5
0.8
2.1
25.4
1003
No. of Cores & Cross Section (mm2)
Nominal insulation Thickness (mm)
Nominal Sheath Thickness (mm)
Overall Dia. (Approx.)(mm)
Total Weight Approx. (kg/km)
30×0.5
0.6
1.5
16.7
364
30×0.75
0.6
1.6
18.3
469
30×1
0.6
1.7
19.6
568
30×1.5
0.7
1.9
22.6
801
30×2.5
0.8
2.2
27.1
1227
37×0.5
0.6
1.6
18.2
236
37×0.75
0.6
1.7
19.9
570
37×1
0.6
1.8
21.3
690
37×1.5
0.7
2.0
24.5
970
37×2.5
0.8
2.4
29.6
1504
48×0.5
0.6
1.8
21.0
574
48×0.75
0.6
1.9
23.0
739
48×1
0.6
2.0
24.6
893
48×1.5
0.7
2.3
28.4
1263
48×2.5
0.8
2.7
34.2
1948
No. of Cores & Cross Section (mm2)
Nominal insulation Thickness (mm)
Nominal Sheath Thickness (mm)
Overall Dia. (Approx.)(mm)
Total Weight Approx. (kg/km)
50×0.5
0.6
1.8
21.1
595
50×0.75
0.6
1.9
23.0
761
50×1
0.6
2.0
24.6
920
50×1.5
0.7
2.3
28.4
1302
50×2.5
0.8
2.7
34.3
2018
54×0.5
0.6
1.8
21.6
631
54×0.75
0.6
2.0
23.8
823
54×1
0.6
2.1
25.5
997
54×1.5
0.7
2.4
29.4
1409
54×2.5
0.8
2.8
35.4
2175
55×0.5
0.6
1.8
21.6
640
55×0.75
0.6
2.0
23.8
834
55×1
0.6
2.1
25.5
1012
55×1.5
0.7
2.4
29.4
1429
55×2.5
0.8
2.8
35.4
2207

Flexible Screened Cable NYSLYCYO

  • Voltage Rate:  300-500 V
  • Applicable  Standard: IEC 60227, IEC 60228

  • Code Designation Of Wire According IEC: 60227 IEC 74
  • Construction:

Conductor: Plain Annealed Copper Wire or Tin Coated Wires(Class 5)

Insulation Type: P.V.C/D

Inner Sheath Type: P.V.C/ST5

Screen: Braided Copper Wire

Outer Sheath Type: P.V.C/ST9

  • Maximum  Conductor  Temperature: 70°C

  • Application:

    Flexible screened cables are used for medium mechanical stress, but without tensile stress or forced movements in dry wet and moist areas but are not suitable for open air application. These cables are used in measuring  and control technics  conveyor belts, production lines, air – conditioning, machine tools etc. the cores are numbered in such way that they  are still  recognizable even after a small part of the outer sheath is  removed. special PVC compound  ensures  good flexibility and  IS  extensively oil resistant.

No. of Cores & Cross Section (mm2)
Nominal insulation Thickness (mm)
Nominal Inner Layer Dia. (mm)
Armour Wire Dia. (mm)
Nominal Sheath Thickness (mm)
Overall Dia. (Approx.)(mm)
Total Weight Approx. (kg/km)
2×0.5
0.6
0.7
0.15
0.9
8.2
88
2×0.75
0.6
0.7
0.15
0.9
8.6
96
2×1
0.6
0.7
0.15
1.0
9.1
107
2×1.5
0.7
0.7
0.15
1.0
9.9
126
2×2.5
0.8
0.7
0.15
1.1
11.4
167
5×0.5
0.6
0.7
0.15
1.0
9.9
130
5×0.75
0.6
0.7
0.15
1.1
10.6
152
5×1
0.6
0.7
0.15
1.1
11.1
170
5×1.5
0.7
0.8
0.15
1.2
12.6
226
5×2.5
0.8
0.8
0.2
1.4
14.8
321
7×0.5
0.6
0.7
0.15
1.1
11.4
161
7×0.75
0.6
0.8
0.15
1.2
12.5
201
7×1
0.6
0.8
0.15
1.3
13.3
232
7×1.5
0.7
0.8
0.2
1.4
15.1
307
7×2.5
0.8
0.8
0.2
1.5
17.3
417
No. of Cores & Cross Section (mm2)
Nominal insulation Thickness (mm)
Nominal Inner Layer Dia. (mm)
Armour Wire Dia. (mm)
Nominal Sheath Thickness (mm)
Overall Dia. (Approx.)(mm)
Total Weight Approx. (kg/km)
12×0.5
0.6
0.8
0.2
1.3
14.0
251
12×0.75
0.6
0.8
0.2
1.4
15.0
298
12×1
0.6
0.8
0.2
1.4
15.8
341
12×1.5
0.7
0.8
0.2
1.6
17.8
448
12×2.5
0.8
0.9
0.2
1.8
21.0
656
19×0.5
0.6
0.8
0.2
1.5
16.1
341
19×0.75
0.6
0.8
0.2
1.5
17.2
408
19×1
0.6
0.9
0.2
1.6
18.5
486
19×1.5
0.7
0.9
0.2
1.8
20.9
656
19×2.5
0.8
1.0
0.2
2.0
24.5
950
24×0.5
0.6
0.9
0.2
1.6
18.7
433
24×0.75
0.6
0.9
0.2
1.7
20.1
522
24×1
0.6
0.9
0.2
1.8
21.4
612
19×1.5
0.7
0.9
0.2
1.8
20.9
656
19×2.5
0.8
1.0
0.2
2.0
24.5
950
No. of Cores & Cross Section (mm2)
Nominal insulation Thickness (mm)
Nominal Inner Layer Dia. (mm)
Armour Wire Dia. (mm)
Nominal Sheath Thickness (mm)
Overall Dia. (Approx.)(mm)
Total Weight Approx. (kg/km)
24×0.5
0.6
0.9
0.2
1.6
18.7
433
24×0.75
0.6
0.9
0.2
1.7
20.1
522
24×1
0.6
0.9
0.2
1.8
21.4
612
24×1.5
0.7
1.0
0.2
2.0
24.4
828
24×2.5
0.8
1.0
0.25
2.3
28.8
1212
30×0.5
0.6
0.9
0.2
1.7
19.7
501
30×0.75
0.6
0.9
0.2
1.8
21.3
614
30×1
0.6
0.9
0.2
1.9
22.6
719
30×1.5
0.7
1.0
0.25
2.1
26.0
994
30×2.5
0.8
1.1
0.25
2.5
30.9
1532
37×0.5
0.6
0.9
0.2
1.8
21.2
588
37×0.75
0.6
0.9
0.2
1.9
22.9
723
37×1
0.6
1.0
0.2
2.0
24.5
861
37×1.5
0.8
1.1
0.25
2.3
28.1
1187
37×2.5
0.8
1.1
0.25
2.6
33.2
1810
No. of Cores & Cross Section (mm2)
Nominal insulation Thickness (mm)
Nominal Inner Layer Dia. (mm)
Armour Wire Dia. (mm)
Nominal Sheath Thickness (mm)
Overall Dia. (Approx.)(mm)
Total Weight Approx. (kg/km)
24×0.5
0.6
0.9
0.2
2.0
24.0
733
48×0.75
0.6
1.0
0.2
2.0
26.6
946
48×1
0.6
1.0
0.25
2.3
28.2
1110
48×1.5
0.7
1.1
0.25
2.6
32.2
1577
48×2.5
0.8
1.2
0.3
3.0
38.4
2347
50×0.5
0.6
0.9
0.2
2.0
24.1
755
50×0.75
0.6
1.0
0.25
2.2
26.6
968
50×1
0.6
1.0
0.25
2.3
28.2
1137
50×1.5
0.7
1.1
0.25
2.6
32.2
1616
50×2.5
0.8
1.2
0.3
3.0
38.5
2418
54×0.5
0.6
1.0
0.2
2.1
25.0
816
54×0.75
0.6
1.0
0.25
2.2
27.2
1023
54×1
0.6
1.0
0.25
2.3
28.9
1207
54×1.5
0.7
1.1
0.25
2.6
33.0
1715
54×2.5
0.8
1.2
0.3
3.1
39.6
2582
55×0.5
0.6
1.0
0.2
2.1
25.0
824
55×0.75
0.6
1.0
0.25
2.2
27.2
1034
55×1
0.6
1.0
0.25
2.3
28.9
1221
55×1.5
0.7
1.1
0.25
2.6
33.0
1735
55×2.5
0.8
1.2
0.3
3.1
39.6
2615

Multicore Screened Instrument Cables MSR- Y (ST) Y

  • Voltage Rate:  300-500 V
  • Applicable  Standard: BS 5308

  • Code Designation Of Wire According IEC: 60227 IEC 74
  • Construction:

:Construction

 Plain Annealed Copper Conductor – Class (1,2,5)

Insulation Type: P.V.C

Screen Over Laying up Cores:  Drain Wire + Aluminum Foil

Sheath: P.V.C

  • Maximum  Conductor  Temperature: 70°C

  • Application:

    Transmission of Analog and Digital Signals in Instrumentation System, the cables are suitable to be laid indoors and outdoors, on the trays or in pipes.

No. of Cores & Cross Section (mm2)
Nominal insulation Thickness (mm)
Nominal Sheath Thickness. (mm)
Overall Dia. (Approx.)(mm)
Total Weight Approx. (kg/km)
2×0.5
0.6
0.8
6.2
44.6
3×0.5
0.6
0.8
6.5
54.8
4×0.5
0.6
0.8
7.1
65.7
5×0.5
0.6
0.9
7.4
78.4
6×0.5
0.6
0.9
8.5
92.1
7×0.5
0.6
1.1
8.9
108.6
8×0.5
0.6
1.1
10.3
125.1
9×0.5
0.6
1.1
11.0
137.9
10×0.5
0.6
1.1
11.0
146.4
11×0.5
0.6
1.2
11.2
160.0
12×0.5
0.6
1.2
11.5
170.7
13×0.5
0.6
1.2
12.0
182.5
14×0.5
0.6
1.2
12.0
191.1
15×0.5
0.6
1.2
12.6
203.6
20×0.5
0.6
1.2
14.0
256.3
25×0.5
0.6
1.3
15.6
315.3
30×0.5
0.6
1.3
16.4
364.0
35×0.5
0.6
1.3
17.7
415.4
40×0.5
0.6
1.3
18.4
463.0
45×0.5
0.6
1.5
20.2
533.7
50×0.5
0.6
1.5
20.5
579.2
55×0.5
0.6
1.5
21.1
626.2
No. of Cores & Cross Section (mm2)
Nominal insulation Thickness (mm)
Nominal Sheath Thickness. (mm)
Overall Dia. (Approx.)(mm)
Total Weight Approx. (kg/km)
2×1
0.6
0.8
7.0
59.3
3×1
0.6
0.9
7.6
78.6
4×1
0.6
0.9
8.2
95.9
5×1
0.6
1.1
8.8
118.8
6×1
0.6
1.1
10.1
140.2
7×1
0.6
1.2
10.2
159.0
8×1
0.6
1.2
11.9
183.5
9×1
0.6
1.2
12.7
202.9
10×1
0.6
1.2
12.7
217.0
11×1
0.6
1.3
12.9
237.0
12×1
0.6
1.3
13.3
253.9
13×1
0.6
1.3
14.0
272.2
14×1
0.6
1.3
14.0
286.3
15×1
0.6
1.3
14.7
305.4
20×1
0.6
1.3
16.2
388.7
25×1
0.6
1.5
18.3
487.4
30×1
0.6
1.5
19.3
566.1
35×1
0.6
1.5
20.8
648.3
40×1
0.6
1.5
21.6
725.5
45×1
0.6
1.7
23.7
830.6
50×1
0.6
1.7
24.1
904.9
55×1
0.6
1.7
24.7
981.3
No. of Cores & Cross Section (mm2)
Nominal insulation Thickness (mm)
Nominal Sheath Thickness. (mm)
Overall Dia. (Approx.)(mm)
Total Weight Approx. (kg/km)
2×1.5
0.6
0.8
7.6
72.6
3×1.5
0.6
1.0
8.4
101.6
4×1.5
0.6
0.9
8.9
120.8
5×1.5
0.6
1.1
9.6
149.9
6×1.5
0.6
1.1
10.9
177.5
7×1.5
0.6
1.2
11.1
202.1
8×1.5
0.6
1.3
13.2
239.0
9×1.5
0.6
1.4
14.3
271.4
10×1.5
0.6
1.4
14.3
290.9
11×1.5
0.6
1.3
14.1
303.9
12×1.5
0.6
1.4
14.8
333.1
13×1.5
0.6
1.3
15.3
350.5
14×1.5
0.6
1.5
15.7
384.1
15×1.5
0.6
1.3
16.1
394.1
20×1.5
0.6
1.3
17.8
506.5
25×1.5
0.6
1.5
20.1
635.0
30×1.5
0.6
1.5
21.3
741.3
35×1.5
0.6
1.5
22.9
851.6
40×1.5
0.6
1.5
23.8
956.2
45×1
0.6
1.7
26.1
1091.8
50×1.5
0.6
1.7
26.5
1193.2
55×1.5
0.6
1.7
27.3
1296.9

Multi Core Screened Armored Instrument Cables MSR-Y (ST) YRY

  • Voltage Rate:  300-500 V
  • Applicable  Standard: BS 5308

  • Construction:

 Plain Annealed Copper Conductor – Class (1,2,5)

Insulation Type: P.V.C

Screen Over Laying up Cores:  Drain Wire + Aluminum Foil

Inner Sheath: P.V.C

Armor: Galvanized Steel Wire

Sheath: P.V.C

  • Application:

    Transmission of Analog and Digital Signals in Instrumentation System, the cables are suitable to be laid indoors and outdoors, on cable trays or in pipes or in earth.

No. of Cores & Cross Section (mm2)
Nominal insulation Thickness (mm)
Nominal Inner Layer Thickness (mm)
Armour Wire Dia. (mm)
Nominal Sheath Thickness. (mm)
Overall Dia. (Approx.)(mm)
Total Weight Approx. (kg/km)
2×0.5
0.6
0.8
0.9
1.3
10.6
44.6
3×0.5
0.6
0.8
0.9
1.3
10.9
238.2
4×0.5
0.6
0.8
0.9
1.3
11.5
262.5
5×0.5
0.6
0.9
0.9
1.4
12.0
287.8
6×0.5
0.6
0.9
0.9
1.4
13.1
323.4
7×0.5
0.6
1.1
0.9
1.5
13.7
358.8
8×0.5
0.6
1.1
1.25
1.5
15.8
495.9
9×0.5
0.6
1.1
1.25
1.5
16.5
523.2
10×0.5
0.6
1.1
1.25
1.5
16.5
531.8
11×0.5
0.6
1.2
1.25
1.6
16.9
564.2
12×0.5
0.6
1.2
1.25
1.6
17.2
587.1
13×0.5
0.6
1.2
1.25
1.6
17.7
612.4
14×0.5
0.6
1.2
1.25
1.6
17.7
621.0
15×0.5
0.6
1.2
1.25
1.6
18.3
647.7
20×0.5
0.6
1.2
1.25
1.6
19.7
739.4
25×0.5
0.6
1.3
1.6
1.7
22.2
985.5
30×0.5
0.6
1.3
1.6
1.7
23.0
1072.9
35×0.5
0.6
1.3
1.6
1.7
24.3
1165.8
40×0.5
0.6
1.3
1.6
1.7
25.0
1234.7
45×0.5
0.6
1.5
1.6
1.9
27.2
1408.0
50×0.5
0.6
1.5
1.6
1.9
27.5
1456.5
55×0.5
0.6
1.5
1.6
1.9
28.1
1524.1
No. of Cores & Cross Section (mm2)
Nominal insulation Thickness (mm)
Nominal Inner Layer Thickness (mm)
Armour Wire Dia. (mm)
Nominal Sheath Thickness. (mm)
Overall Dia. (Approx.)(mm)
Total Weight Approx. (kg/km)
2×0.75
0.6
0.8
0.9
1.3
11.0
236.1
3×0.75
0.6
0.8
0.9
1.3
11.4
256.4
4×0.75
0.6
0.8
0.9
1.4
12.2
289.6
5×0.75
0.6
0.9
0.9
1.4
12.6
318.1
6×0.75
0.6
0.9
0.9
1.4
13.7
357.6
7×0.75
0.6
1.1
0.9
1.5
14.3
396.6
8×0.75
0.6
1.1
1.25
1.5
16.5
547.7
9×0.75
0.6
1.1
1.25
1.5
17.3
578.8
10×0.75
0.6
1.1
1.25
1.5
17.3
590.2
11×0.75
0.6
1.2
1.25
1.6
17.7
626.2
12×0.75
0.6
1.2
1.25
1.6
18.1
652.4
13×0.75
0.6
1.2
1.25
1.6
18.7
681.4
14×0.75
0.6
1.2
1.25
1.6
18.7
692.8
15×0.75
0.6
1.2
1.25
1.6
19.3
732.8
20×0.75
0.6
1.2
1.6
1.6
21.5
960.8
25×0.75
0.6
1.3
1.6
1.8
23.6
1133.4
30×0.75
0.6
1.3
1.6
1.8
24.6
1220.7
35×0.75
0.6
1.3
1.6
1.8
26.0
1346.2
40×0.75
0.6
1.3
1.6
1.8
26.7
1430.6
45×0.75
0.6
1.5
1.6
2.0
29.07
1624.2
50×0.75
0.6
1.5
1.6
2.0
29.4
1687.5
55×0.75
0.6
1.5
1.6
2.0
30.0
1786.6
No. of Cores & Cross Section (mm2)
Nominal insulation Thickness (mm)
Nominal Inner Layer Thickness (mm)
Armour Wire Dia. (mm)
Nominal Sheath Thickness. (mm)
Overall Dia. (Approx.)(mm)
Total Weight Approx. (kg/km)
2×1
0.6
0.8
0.9
1.4
11.6
255.6
3×1
0.6
0.9
0.9
1.4
12.2
288.9
4×1
0.6
0.9
0.9
1.4
12.8
320.5
5×1
0.6
1.1
0.9
1.4
13.4
357.3
6×1
0.6
1.1
0.9
1.4
14.6
406.9
7×1
0.6
1.2
1.25
1.6
15.9
536.8
8×1
0.6
1.2
1.25
1.6
17.6
612.3
9×1
0.6
1.2
1.25
1.6
18.4
657.4
10×1
0.6
1.2
1.25
1.6
18.4
671.6
11×1
0.6
1.3
1.25
1.7
18.8
701.6
12×1
0.6
1.3
1.25
1.7
19.2
731.3
13×1
0.6
1.3
1.25
1.7
19.9
764.1
14×1
0.6
1.3
1.25
1.7
19.9
778.3
15×1
0.6
1.3
1.25
1.7
20.6
822.4
20×1
0.6
1.3
1.6
1.7
22.8
1080.1
25×1
0.6
1.5
1.6
1.9
25.3
1281.7
30×1
0.6
1.5
1.6
1.9
26.3
1401.2
35×1
0.6
1.5
1.6
1.9
27.8
1544.1
40×1
0.6
1.5
1.6
1.9
28.6
1644.3
45×1
0.6
1.7
1.6
2.1
31.1
1859.4
50×1
0.6
1.7
1.6
2.1
31.5
1953
55×1
0.6
1.7
1.6
2.1
32.1
2052.1
No. of Cores & Cross Section (mm2)
Nominal insulation Thickness (mm)
Nominal Inner Layer Thickness (mm)
Armour Wire Dia. (mm)
Nominal Sheath Thickness. (mm)
Overall Dia. (Approx.)(mm)
Total Weight Approx. (kg/km)
2×1.5
0.6
0.8
0.9
1.4
12.2
282.9
3×1.5
0.6
1.0
0.9
1.4
13.0
332.5
4×1.5
0.6
0.9
0.9
1.4
13.5
365.1
5×1.5
0.6
1.1
0.9
1.4
14.2
408.4
6×1.5
0.6
1.1
1.25
1.4
16.2
555.3
7×1.5
0.6
1.2
1.25
1.6
16.8
606.0
8×1.5
0.6
1.3
1.25
1.6
18.9
706.6
9×1.5
0.6
1.4
1.25
1.6
20.0
766.9
10×1.5
0.6
1.4
1.25
1.6
20.0
786.4
11×1.5
0.6
1.3
1.25
1.7
20.0
807.0
12×1.5
0.6
